Name: QTY-25 Pneumatic Pressure Regulator 1.0MPa 1 inch Regulator with Gauge QTY25
Brand: Ningbo Brando Hardware Co., Ltd
SKU: QTY-25
Price: 49.10 USD
Availability: InStock

Home Products Filter Regulator Lubricator

QTY-25 Pneumatic Pressure Regulator 1.0MPa 1 inch Regulator with Gauge QTY25

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	QTY-25

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Product Name:

Pneumatic Regulator

Port Size:

G1''

Working Pressure:

0.5 To 10 Bar

Fluid:

Air

Highlight:

QTY Series Pressure Regulator Valve

QTY-25 Pneumatic Pressure Regulator

Pneumatic QTY Air Regulator

QTY-25 Pneumatic Pressure Regulator 1.0MPa 1 inch Regulator with Gauge QTY25

QTY series pneumatic regulators, also called pressure reducing valves, QTY-08, QTY-10, QTY-15, QTY-20, QTY-25, QTY-35, QTY-40, QTY-50, QTY-65, QTY-80 models, 1/4'' to 3'' port sizes, aluminum body, NBR diaphragm, 0.5 to 10 bar working pressure, 100L/min to 3200L/min high flow. If you have any demands, pls contact us!

Technical Data:

Model No	QTY-08	QTY-10	QTY-15	QTY-20	QTY-25	QTY-35	QTY-40	QTY-50
Port Size	G1/4''	G3/8''	G1/2''	G3/4''	G1''	G1-1/4''	G1-1/2''	G2''
Working Medium	Air
Working Pressure	0.5 to 10 bar
Working Temperature	-5 to 60ºC
Valve Type	With Overflow

Main Dimension:

Model No	Port	A	B	D	D1	D2	D3	D4	L0	L1	L2	L3	E	L max.
QTY-08	G1/4''	74	64	80	44	60	52	60	20	57	70	8	70	180
QTY-10	G3/8''	74	64	80	44	60	52	60	20	57	70	8	70	180
QTY-15	G1/2''	74	64	80	44	60	52	60	20	57	70	8	70	180
QTY-20	G3/4''	106	105	120	60	97	52	90	30	77	108	9	85	240
QTY-25	G1''	106	105	120	60	97	52	90	30	77	108	9	85	240
QTY-35	G1-1/4''	133	100	120	64	97	52	90	40	110	108	9	95	275
QTY-40	G1-1/2''	133	100	120	64	97	52	90	35	110	108	9	90	275
QTY-50	G2''	133	100	120	64	97	52	90	35	110	108	9	90	275

Our Production:

Related Products:


Pneumatic Valve	Pneumatic Cylinder	Pneumatic FRL	Pneumatic Fitting

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
