| Place of Origin: | CHINA |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | AF, BF |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | bubble bag, inner box, carton, then pallet |
| Delivery Time: | 7 working days after payment |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000pcs per month |
| Product Name: | Pneumatic Filter | Fluid: | Air |
|---|---|---|---|
| Port Size: | 1/8'', 1/4'', 3/8'', 1/2'' | Filtering Grade: | 40 μm Or 5 μm |
| Proof Pressure: | 1.5Mpa (215Psi) | Capacity Of Drain Bowl: | 15CC, 60CC |
| Temperature Range: | -5 To 70℃ (unfreeze) | ||
| High Light: | Airtac Air Filter,Airtac Pneumatic Filter,Airtac Pneumatic Air Filter |
||
Airtac Type Pneumatic Air Filter AF1500 AF2000 BF2000 BF3000 BF4000
Product Features of AF, BF series Pneumatic Filter:
AF Series
1.The structure is delicate and compact.
2.The pressure loss is low and the efficiencyof water separating is high;
3.The filter precision includes 5μm and 40μm (optional);
BF Series
1.The pressure loss is low and the efficiency ofwater separating is high.
2.The bowl has high-strength plastic shields outside, which is more safe and reliable to use.
3.The filter precision includes 5μm and 40μm (optional).
Specification of AF, BF series Pneumatic Filter:
|
Model
|
AF1500
|
AF2000
|
BF2000
|
BF3000
|
BF4000
|
|
|
Fluid
|
Air
|
|||||
|
Port Size
|
1/8''
|
1/4''
|
1/4''
|
3/8''
|
1/2''
|
|
|
Filtering Grade
|
40μm or 5μm
|
|||||
|
Pressure Range
|
Semi-auto and automatic drain: 0.15 to 1.0 MPa (20 to 145 psi)
Manual drain: 0 to 1.0 MPa (0 to 145 psi) |
|||||
|
Proof Pressure
|
1.5 MPa (215 psi)
|
|||||
|
Temperature Range
|
-5 to 70℃ (unfreeze)
|
|||||
|
Capacity of drain bowl
|
15CC
|
60CC
|
||||
Ordering Code of AF, BF series Pneumatic Filter:
Dimension of AF, BF series Pneumatic Filter:
Inner Structure of AF, BF series Pneumatic Filter:
BRANDO Supply Filter Regulator Lubricator:
| Filter Regulator Lubricator Airtac Type | Filter Regulator Lubricator SMC Type | Filter Regulator Lubricator Festo Type |
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
