Name: AirTAC Type 4V320-10 DC12V 3/8'' Double Solenoid 5/2 way Solenoid Air Valve
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 4V320-10
Price: 49.10 USD
Availability: InStock

Home Products Pneumatic Solenoid Valve

AirTAC Type 4V320-10 DC12V 3/8'' Double Solenoid 5/2 way Solenoid Air Valve

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	4V320-10

Payment & Shipping Terms:

Minimum Order Quantity:	300pcs
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	In=Out=3/8'', Exhaust=1/4''	Pressure Range:	0.15 To 0.8 MPa
Body Material:	Aluminum Alloy	Valve Type:	5/2 Way, Double Solenoid
Max Pressure Resistance:	1.5MPa (215PSI)	Fluid:	Air
Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Highlight:	Airtac 4V300 solenoid air valve series , Airtac 4V320-10 Solenoid Air Valve , Solenoid Valve AirTAC 4V320-10

AirTAC Type 4V320-10 DC12V 3/8'' Double Solenoid 5/2 way Solenoid Air Valve

Pneumatic solenoid valves control airflow by applying electricity to the solenoid. These components are designed to stop, start or change the direction of airflow.

We carry numerous port and position configurations. Most air control valves are available with AC220V, DC24V, AC110V, AC24V or DC12V solenoid coils. Choose from the 5/2 way NAMUR type, 3/2 way, or the 5/2 way and 5/3 way.

When choosing thread type, please reference the following standards:
NPT - American standard taper pipe threads for general use
M - Metric screw threads M profile
Rp or G (BSPP) - British standard pipe (parallel) threads
PT - JIS taper pipe threads

Data of 4V300 Series Pneumatic Solenoid Valves:

Model	4V310-08 4V320-08	4V330C-08 4V330E-08 4V330P-08	4V310-10 4V320-10	4V330C-10 4V330E-10 4V330P-10
Fluid	Air(to be filtered by 40 μ m filter element)
Acting	Internal pilot or external pilot
Port Size	In=Out=Exhaust=1/4''		In=Out=3/8'' Exhaust=1/4''
Orifice Size	25.00 mm2 (Cv=1.40)	18.00 mm2 (Cv=1.00)	30.00 mm2 (Cv=1.68)	18.00 mm2 (Cv=1.00)
Valve Type	5 port 2 position	5 port 3 position	5 port 2 position	5 port 3 position
Operating Pressure	0.15~0.8MPa(21~114psi)
Proof Pressure	1.5MPa(215psi)
Temperature ℃	-20~70
Material of Body	Aluminum alloy
Max. frequency	4 cycle/sec	4 cycle/sec	4 cycle/sec	4 cycle/sec
