Name: Airtac Type 4V120-06 Solenoid Air Valve 5/2 Double Pneumatic Solenoid valve
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 4V120-06
Price: 49.10 USD
Availability: InStock

Home Products Pneumatic Solenoid Valve

Airtac Type 4V120-06 Solenoid Air Valve 5/2 Double Pneumatic Solenoid valve

Product Details:

Place of Origin:	CHINA
Brand Name:	BRANDO
Certification:	None
Model Number:	4V120-06

Payment & Shipping Terms:

Minimum Order Quantity:	300pcs
Price:	Negotiation
Packaging Details:	Inner Box,Carton,Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	In=Out=1/8''	Pressure Range:	0.15 To 0.8 MPa
Body Material:	Aluminum Alloy	Valve Type:	5 Port 2 Position
Max Pressure Resistance:	1.2MPa	Fluid:	Air (to Be Filtered By 40 μm Filter Element)
Voltages:	220V AC, 110V AC, 24V AC, 24V DC, 12V DC
Highlight:	Solenoid Valve 4V120-06 , 4V100 Series Solenoid Valve , Pneumatic Solenoid Valve 4V120-06

Airtac Type 4V110-06 Single Solenoid Pneumatic Air Valve 4V100 Series

Pneumatic valve is where air or an inert gas is the pneumatic drive force. These type of pneumatic valves control or manage the source air within an automated system. While frequently referred to as pneumatic valves, they can be actuated (operated) by manually, by pneumatic actuation (Air Pilot Valve), by solenoid actuation (Pneumatic Solenoid Valve), or by motorized actuation. Ultimately, they all serve the same purpose: they modulate or control the source air for an automated system.

Data of 4V100 Series Pneumatic Solenoid Valves:

Model	4V110-06 4V120-06	4V130C-06 4V130E-06 4V130P-06	4V110-08 4V120-08	4V130C-08 4V130E-08 4V130P-08
Fluid	Air(to be filtered by 40 μ m filter element)
Acting	Internal pilot or external pilot
Port Size	In=Out=1/8''		In=Out=1/4''
Orifice Size	5.5 mm2 (Cv=0.31)	5.0 mm2 (Cv=0.28)	12.00 mm2 (Cv=0.67)	9.00 mm2 (Cv=0.50)
Valve Type	5 port 2 position	5 port 3 position	5 port 2 position	5 port 3 position
Operating Pressure	0.15~0.8MPa (21~114psi)
Proof Pressure	1.5MPa (215psi)
Temperature ℃	-20~70
Material of Body	Aluminum alloy
Max. frequency	5 cycle/sec	3 cycle/sec	5 cycle/sec	3 cycle/sec

Main Dimension of 4V120-06 Solenoid Valve:

Airtac Type 4V120-06 Solenoid Air Valve 5/2 Double Pneumatic Solenoid valve 0

Production Video of Pneumatic Solenoid Valves:

More Pneumatic Products for you to choose:

Airtac Type 4V120-06 Solenoid Air Valve 5/2 Double Pneumatic Solenoid valve 1

Solenoid Operator Manifold Silencer Pneumatic Hose Fittings

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!

Tag:

Contact Person: Mr. Brandon Bao

Tel: 86-13454729544

Fax: 86-574-83879820
