EVI 7/9 AMISCO Type 22mm Solenoid Coils for Pneumatics 12V 24V 110V 220V 22VA 20W

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	None
Model Number:	BB09029504

Payment & Shipping Terms:

Minimum Order Quantity:	200
Price:	Negotiation
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	Negotiation
Payment Terms:	T/T,PayPal,Western Union
Supply Ability:	100000pcs per month

Contact Now

Detailed Product Description

Product Name:	Solenoid Valve Coil	Voltage:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Power:	3W, 4.8W, 5W, 6.5W, 5VA, 6.5VA	Connector:	Flying Leads
Protection Class:	IP65	Ordering Code:	EVI 7/9
Highlight:	solenoid valve coil EVI 7/9 24VDC 6.5W , AMISCO EVI 7/9 AC110V , AMISCO EVI 7 series

EVI 7/9 AMISCO Type 22mm Solenoid Coils for Pneumatics 12V 24V 110V 220V 22VA 20W

This EVI 7/9 solenoid coil with flying leads is popularly used in many solenoid valves, like 2V025-06, 2V025-08, 2P025-06, 2P025-08, 3V1-06, etc. Solenoid Coil Standard Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC. Solenoid Coil Standard Power: 4.8W, 6.5W, 6.5VA. The solenoid coil is integral in the operation of a Solenoid Valve. It is what converts the electric current into a magnetic field which in turn allows the operation of the solenoid valve.

Dimension & Data of Solenoid Coil EVI 7/9:

EVI 7/9 AMISCO Type 22mm Solenoid Coils for Pneumatics 12V 24V 110V 220V 22VA 20W 0

BRANDO Model	BB09029504
Voltage	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Power	3W, 4.8W, 5W, 6.5W, 5VA, 6.5VA
Other voltage and power can be customized
Insulation Class	F, H
Connector	Flying Leads

EVI 7/9 AMISCO Type 22mm Solenoid Coils for Pneumatics 12V 24V 110V 220V 22VA 20W 1

BRANDO Model	BAPC209029003
Function	2 Way Normally Closed
Plunger Tube Material	Brass
Seal Material	NBR, FKM, EPDM
Connection Type	Flange with O-ring Groove

Video of Solenoid Valve Coil EVI 7/9:

BRANDO Solenoid Valve Coils Production Video:

More Solenoid Valves for you to choose:


Brass Solenoid Valve	Stainless Steel Solenoid Valve	Plastic Solenoid Valve

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
