Name: M45 TKISM45 Turbo Diaphragm Repair Kit for 1-1/2'' TI045P TI045M
Brand: Ningbo Brando Hardware Co., Ltd
SKU: M45
Price: 49.10 USD
Availability: InStock

Home Products Diaphragm Repair Kit

M45 TKISM45 Turbo Diaphragm Repair Kit for 1-1/2'' TI045P TI045M

Product Details:

Place of Origin:	China
Brand Name:	Ningbo BRANDO
Certification:	None
Model Number:	M45

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	T/T,Western Union,PayPal
Supply Ability:	100000pcs per month

Contact Now

Detailed Product Description

Product Name:	Pulse Valve Diaphragm	Ref No:	TKITM45, TKISM045N, TKISM045V, TKISM045T
Diaphragm Material:	NBR, VITON	Fitted Pulse Valve Port:	1-1/2''
Fitted Pulse Valve Model:	TI045P, TI045M	1 Set:	1pc M45 Diaphragm, 1pc M10 Diaphragm, 2pcs Springs
Highlight:	TKISM45 Turbo Diaphragm Repair Kit , TURBO M45 Diaphragm , TURBO M45 Membrane

M45 TKISM45 Turbo Diaphragm Repair Kit for 1-1/2'' TI045P TI045M

This M45 diaphragm is usded in TUBRO TI045P and TI045M pulse valves. The diaphragm is the most important part of the pulse valve. When the pulse valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pulse valve is de-energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the pulse valve.

Ordering Code of Diaphragm For Turbo Pulse Valve:

Diaphragm Model No	Pulse Valve Model No	Pulse Valve Port Size	Diaphragm Material
M25	FP20, FM20, FP25, FM25, DP20, DM20, DP25, DM25, EP25, EM25, SQP20, SQM20, SQP25, SQM25, FDP20, FDM20, FDP25, FDM25	3/4'', 1''	NBR (standard) FKM (optional)
M40+M25	FP40, FM40, DP40, DM40, EP40, EM40	1-1/2''
M45+M10	TI045P, TI045M	1-1/2''
M50+M25	FP50, FM50, FP55, FM55, SQP50, SQM50, SQP55, SQM55, SQP60, SQM60, SQP65, SQM65	2'', 2-1/2''
M75+M25	FP65, FM65, SQP75, SQM75	2-1/2'', 3''
M100+M25	SQP100, SQM100	3-1/2'', 4''

M45 Dimension:

M45 TKISM45 Turbo Diaphragm Repair Kit for 1-1/2'' TI045P TI045M 0

Pictures of Pulse Valve Membrane Production:

More Turbo Type Pulse Jet Valve for you to choose:


Threaded Type	Submerged Type	Valve Diaphragm

Solenoid Coil	Solenoid Armature	Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
