Name: Taeha Type MD03-60 Diaphragm Repair Kit for Taeha 2.5 Inches TH-4460-B TH-4460-S Membrane
Brand: Ningbo Brando Hardware Co., Ltd
SKU: MD03-50
Price: 49.10 USD
Availability: InStock

Home Products Diaphragm Repair Kit

Taeha Type MD03-60 Diaphragm Repair Kit for Taeha 2.5 Inches TH-4460-B TH-4460-S Membrane

Product Details:

Place of Origin:	China
Brand Name:	Ningbo BRANDO
Certification:	None
Model Number:	MD03-50

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	T/T,Western Union,PayPal
Supply Ability:	100000pcs per month

Contact Now

Detailed Product Description

Product Name:	Pulse Valve Diaphragm	Diaphragm Material:	NBR
Seat Material:	Nylon	Fitted Pulse Valve Port:	2''
Fitted Pulse Valve Model:	TH-5450-B, TH-4450-B	1 Set:	1pc Big Diaphragm, 1pc Small Diaphragm, 2pcs Springs
Highlight:	Taeha Diaphragm Kit MD03-60 , Taeha Membrane Kit MD03-60 , Membrane For Taeha Pulse Valve

Taeha Type MD03-60 Diaphragm Repair Kit for Taeha 2.5 Inches TH-4460-B TH-4460-S Membrane

MD03-50 Diaphragm (Membrane) for Taeha pulse valve TH-5450-B, TH-4450-B; The diaphragm is the most important part of the pulse valve. When the pulse valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pulse valve is de-energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the pulse valve.

Ordering Code of Diaphragm For Taeha Pulse Valve:

BRANDO Model	Diaphragm Model	Pulse Valve Port Size	Pulse Valve Model No	Diaphragm Color	Diaphragm Material
DH20	MD01-20 MD02-20	3/4''	TH-5820-B TH-4820-B TH-5825-B TH-5820-C TH-4820-C	Red & Green	NBR
DH25	MD01-25 MD02-25	1''	TH-4825-B TH-5825-C TH-4825-C TH-5840-F TH-4840-F
DH25	MD01-25M	1''	TH-5825-M
DH30	MD01-30 MD02-30 MD03-30	1 1/4''	TH-5830-B TH-5430-B TH-4830-B TH-4430-B
DH30	MD03-30M	1 1/4''	TH-5430-M TH-4430-M
DH40	MD01-40 MD02-40 MD03-40	1 1/2''	TH-5840-B TH-5440-B TH-4840-B TH-4440-B TH-5840-C TH-5440-C TH-4840-C TH-4440-C TH-5850-F TH-5450-F TH-4850-F TH-4450-F
DH40M	MD03-40M	1 1/2''	TH-5440-M TH-4440-M
DH50	MD03-50	2''	TH-5450-B TH-4450-B
DH50M	MD03-50M	2''	TH-5450-M TH-4450-M
DH60	MD03-60 MD04-60	2 1/2''	TH-5460-B TH-4460-B TH-5460-S TH-4460-S
DH75	MD03-75	3''	TH-5475-B TH-4475-B
DH75	MD03-75M	3''	TH-5475-M TH-4475-M
DH90M	MD03-90M	3 1/2''	TH-5490-M TH-4490-M
DH100M	MD03-00M	4''	TH-5400-M TH-4400-M

Main Dimension of MD03-50 Diaphragm:


Main Diaphragm	Secondary Diaphragm

Pulse Valve Diaphragm Production Pictures:

Related Products:


Solenoid Coil	Solenoid Armature	Pulse Valve	Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!

Tag:

Contact Person: Mr. Brandon Bao

Tel: 86-13454729544

Fax: 86-574-83879820
