Name: Diaphragm For BFEC 2'' Dust Collector Pulse Valve DMF-Z-50S DMF-Y-50S DMF-T-50S
Brand: Ningbo Brando Hardware Co., Ltd
SKU: D50
Price: 49.10 USD
Availability: InStock

Home Products Diaphragm Repair Kit

Diaphragm For BFEC 2'' Dust Collector Pulse Valve DMF-Z-50S DMF-Y-50S DMF-T-50S

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	None
Model Number:	D50

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Plastic Bags, Cartons, Pallet
Delivery Time:	4-7 Days
Payment Terms:	T/T,Western Union,Paypal,MoneyGram
Supply Ability:	200000 pcs per month

Contact Now

Detailed Product Description

Product Name:	Diaphragm Repair Kit	Mounting Hole Size:	φ8mm
Diaphragm Material:	NBR (Nitrile)	Diaphragm OD:	φ160mm
Center Distance:	φ142mm	Seat Material:	Nylon
Seat OD:	φ75mm	Seat ID:	φ39mm
Bleed Hole:	1	Spring:	2
Packaging:	Individual Plastic Bag Sealed	Suitable Valves:	DMF-Z-50S, MF-Z-50S, DMF-Y-50S, MF-Y-50S, DMF-T-50S, MF-T-50S
Highlight:	BFEC Membrane Repair Kit , Dust Collector Membrane Kit , SBFEC 2'' Diaphragm Kit

Diaphragm For BFEC 2'' Dust Collector Pulse Valve DMF-Z-50S DMF-Y-50S DMF-T-50S

The introduced is a BFEC Nylon seat NBR diaphragm repair kit for 2'' DMF-Z-50S, MF-Z-50S, DMF-Y-50S, MF-Y-50S, DMF-T-50S, MF-T-50S pulse valves. Pulse valve also called diaphragm valve that is the ”switch” for compressed air in the dust clean blowing system of the pulse bag filter. Controlled by the output signals of the pulse control device, it makes dust clean to the filter bags cell by cell to keep the resistance of the bag filter within the sec range and thus guarantee the processing functions and the dust collecting efficiency of the bag filter dust collector.

YouTube video of 2'' BFEC Nylon Seat NBR Diaphragm Repair Kit:

Main dimension of MF/DMF-Z-50S MF/DMF-Y-50S MF/DMF-T-50S Diaphragm:

Diaphragm For BFEC 2'' Dust Collector Pulse Valve DMF-Z-50S DMF-Y-50S DMF-T-50S 0

Details display of BFEC 2'' DMF/MF Diaphragm Valve Repair Kit:

Diaphragm For BFEC 2'' Dust Collector Pulse Valve DMF-Z-50S DMF-Y-50S DMF-T-50S 1

Available Models of BFEC DMF/MF Diaphragm Valve Repair Kits:

Ordering Code	Fitted Valve Code	Port Size
DTY	MF/DMF-T-25S, MF/DMF-T-40S, MF/DMF-T-50S, MF/DMF-T-62S, MF/DMF-ZM-40S, MF/DMF-Y-40S, MF/DMF-Y-50S, MF/DMF-Y-62S, MF/DMF-Y-76S, MF/DMF-YA-76S, MF/DMF-YB-76S, MF/DMF-Y-102S, MF/DMF-Y-102SA, MF/DMF-Y-102SE, MF/DMF-ZF-40S, MF/DMF-Z-40S, MF/DMF-Z-50S, MF/DMF-Z-62S, MF/DMF-Z-76S, MF/DMF-Z-102S	Tip: Secondary Diaphragm
D20A	DMF-Z-20, MF-Z-20, DMF-ZM-20, MF-ZM-20	3/4''
D25	DMF-Z-25, MF-Z-25, DMF-ZM-25, MF-ZM-25, DMF-ZF-25, MF-ZF-25, DMF-Y-25, MF-Y-25, DMF-T-20, MF-T-20	3/4'' & 1''
D40	DMF-Z-40S, MF-Z-40S, DMF-Y-40S, MF-Y-40S, DMF-ZF-40S, MF-ZF-40S, DMF-ZM-40S, MF-ZM-40S, DMF-T-25S, MF-T-25S	1'' & 1-1/2''
D50	DMF-Z-50S, MF-Z-50S, DMF-Y-50S, MF-Y-50S, DMF-T-50S, MF-T-50S	2''
D62	DMF-Z-62S, MF-Z-62S, DMF-Y-62S, MF-Y-62S	2-1/2''
D76	DMF-Z-76S, MF-Z-76S, DMF-Y-76S, MF-Y-76S	3''
D102	DMF-Z-102S, MF-Z-102S, DMF-Y-102S, MF-Y-102S	4''
D102A	DMF-Y-102SA, MF-Y-102SA	4''
DZL-20B	DMF-ZL-B, MF-ZL-B	3/4''

Tips: The valves mentioned, related solenoid coils and armature assembly are all supplied.

Factory Production Pictures of Solenoid Valve Diaphragm Kits:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
