LPG CNG Auto Part Solenoid Coil 12VDC 12 Volt DC12V 48W

LPG CNG Auto Part Solenoid Coil 12VDC 12 Volt DC12V 48W


1. Product Name: LPG CNG Solenoid Coil For Injector Rail
2. Supply Voltages: 12V DC, Resistance: 2 Ohm, 3 Ohm, 4 Ohm
3. Solenoid Coil Inuslation Class is H, F
4. Solenoid Coil Portdction Class is IP65, IP67
5. Connector Type: DEUTSCH.
6. Brando supply all kinds of solenoid coils to repair many brand injector rail, such like BRC (IN03 MY09R), LOVATO, OMVL (REG), AEB (INJ R2S R3S R4S), VALTEK (Type 30), ATIKER, RAIL (IG7 Dakota) and so on.

The dual-fuel vehicle is equipped with a LPG supply system while retaining the original vehicle fuel system. It can be freely converted between gasoline and LPG as needed during use. When a car burns LPG and burns gasoline, the driver only needs to operate the accelerator pedal to change the working condition of the engine and adapt to the driving performance requirements of the car.

Technical parameter of BB11014014 solenoid coils:


Main dimenison of BB11014014 solenoid coil:



Other electromagnetic coils for your reference:


Dual fuel car LPG system composition and working principle
1. The main composition and working principle of the dual fuel car LPG system
The system consists of a gas storage tank, an evaporation regulator, a gasoline solenoid valve, an LPG solenoid valve, a power regulating valve, a venturi mixer, a fuel transfer switch, and a control circuit.
When the fuel transfer switch is turned to the LPG position, the gasoline solenoid valve is de-energized (cutting off the gasoline supply) and the LPG solenoid valve is energized. The LPG liquid comes out of the gas storage tank, passes through the LPG solenoid valve to the evaporation regulator, and is depressurized and vaporized to become a gas close to atmospheric pressure. The LPG gas flows through the power regulating valve to the venturi mixer, is thoroughly mixed with the air in the venturi mixer, and supplies a certain amount of LPG gas to the carburetor throat (acting only as a channel) according to the operating conditions of the engine.
2. Gas storage tank
The gas storage tank is installed in the luggage compartment at the rear of the vehicle. Its function is to store the LPG. The integrated valve is installed on it to ensure the safe use of the gas storage tank and the whole system.
Solenoid Coil Production Line:
