Name: TKITM100N04 Diaphragm For 3.5'' SQP100 SQM100 TURBO Pulse Valve
Brand: Ningbo Brando Hardware Co., Ltd
SKU: M100
Price: 49.10 USD
Availability: InStock

Home Products Diaphragm Repair Kit

TKITM100N04 Diaphragm For 3.5'' SQP100 SQM100 TURBO Pulse Valve

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	M100

Payment & Shipping Terms:

Minimum Order Quantity:	10sets
Price:	Negotiation
Packaging Details:	Plastic bag, Box, Carton, Pallet
Delivery Time:	4 to 7 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	100000 sets per month

Contact Now

Detailed Product Description

Product Name:	Pulse Valve Diaphragm	Diaphragm Material:	NBR
Fitted Pulse Valve Port Size:	3.5'', 4''	Fitted Pulse Valve Model No:	SQP100, SQM100
1 Set:	1pc M100 Diaphragm, 1pc M25 Diaphragm, 2pcs Springs
Highlight:	TKITM100N04 Diaphragm , SQP100 Diaphragm , Turbo TKITM100N04 Membrane

TKITM100N04 Diaphragm For 3.5'' SQP100 SQM100 TURBO Pulse Valve

The diaphragm is the most important part of the pulse valve. When the pulse valve is energised, the trapped air above pulse valve diaphragm is quickly exhausted causing fast opening of main diaphragm valve. When the pulse valve is de-energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the pulse valve.

M100 Dimension:

TKITM100N04 Diaphragm For 3.5'' SQP100 SQM100 TURBO Pulse Valve 0

Order Code:

Diaphragm Model No	Pulse Valve Model No	Pulse Valve Port Size	Diaphragm Material
M25	FP20, FM20, FP25, FM25, DP20, DM20, DP25, DM25, EP25, EM25, SQP20, SQM20, SQP25, SQM25, FDP20, FDM20, FDP25, FDM25	3/4'', 1''	NBR (standard) FKM (optional)
M40 & M25	FP40, FM40, DP40, DM40, EP40, EM40	1-1/2''
M50 & M25	FP50, FM50, FP55, FM55, SQP50, SQM50, SQP55, SQM55, SQP60, SQM60, SQP65, SQM65	2'', 2-1/2''
M75 & M25	FP65, FM65, SQP75, SQM75	2-1/2'', 3''
M100 & M25	SQP100, SQM100	3-1/2'', 4''

Our Production:

TKITM100N04 Diaphragm For 3.5'' SQP100 SQM100 TURBO Pulse Valve 1

Related Products:


Solenoid Coil	Solenoid Armature	Pulse Valve	Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
