| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 616BA-30 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Function: | 2 Way, Normally Closed | Operation: | Direct Acting |
|---|---|---|---|
| Port Size: | 1/8'' | Orifice Size: | 3mm |
| Voltages: | 12VDC, 24VDC, 110VAC, 220VAC | Fluids: | Corrosive Liquid, Acid And Alkali |
| Valve Body Material: | PTFE | Seal Material: | PTFE |
| Working Pressure Range: | 0 To 0.3 MPa | ||
| High Light: | 1/8'' PTFE Solenoid Valve,Isolation PTFE Solenoid Valve,Anti Corrosion Solenoid Valve |
||
1/8'' Acid Alkali Corrosion Resistance Isolation PTFE Solenoid Valve
Product Features:
Our isolation solenoid valves offer instrument designers a completely inert, non-metallic fluid path. The valves use a flexible diaphragm to isolate the solenoid actuation mechanism from the fluid path. Isolation Valves offer low internal volumes, precise flow control and excellent ease of installation making them particularly suitable for use in highly aggressive and / or high purity fluid applications such as analytical chemistry and clinical diagnostics. The highly inert fluid path is especially useful in liquid chromatography, genomics and protein synthesis applications. The high flow factor makes these valves well suited to environmental and water analysis applications.
Technical Data of Isolation Solenoid Valve:
| Model No. | Port size | Orifice (mm) | Cv | Mini Pressure | Max Pressure | Seal Material | |||
| AC(6VA) | DC(10W) | ||||||||
| 6.16BAP030BM8 | M8x1 | 3.0 | 0.1 | 0.0MPa | 0.3MPa | 0.3MPa | PTFE | ||
| 6.16BAP030B01 | 1/8'' | 3.0 | 0.1 | 0.0MPa | 0.3MPa | 0.3MPa | |||
| 6.16BAP030B02 | 1/4'' | 3.0 | 0.1 | 0.0MPa | 0.15MPa | 0.15MPa | |||
| AC(24VA) | DC(13W) | ||||||||
| 6.16BAP060B02 | 1/4'' | 6.0 | 0.28 | 0.0MPa | 0.15MPa | 0.15MPa | |||
| 6.16BAP060B03 | 3/8'' | 6.0 | 0.28 | 0.0MPa | 0.15MPa | 0.15MPa | |||
| 6.16BAP060B04 | 1/2'' | 6.0 | 0.28 | 0.0MPa | 0.15MPa | 0.15MPa | |||
| 6.16BAP060B06 | 3/4'' | 6.0 | 0.28 | 0.0MPa | 0.15MPa | 0.15MPa | |||
Main Dimension of Isolation Solenoid Valve:
