| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | M100 |
| Minimum Order Quantity: | 10sets |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 100000 sets per month |
| Product Name: | Pulse Valve Diaphragm | Diaphragm Material: | NBR |
|---|---|---|---|
| Fitted Pulse Valve Port Size: | 3.5'', 4'' | Fitted Pulse Valve Model No: | SQP100, SQM100 |
| 1 Set: | 1pc M100 Diaphragm, 1pc M25 Diaphragm, 2pcs Springs | ||
| High Light: | TURBO Diaphragm M100,TURBO Diaphragm TKITM100N04,TURBO Pulse Valve Diaphragm |
||
M100 TKITM100N04 Diaphragm For TURBO Pulse Valve SQP100 SQM100
The diaphragm is the most important part of the pulse valve. When the pulse valve is energised, the trapped air above pulse valve diaphragm is quickly exhausted causing fast opening of main diaphragm valve. When the pulse valve is de-energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the pulse valve.
M100 Dimension:
Order Code:
|
Diaphragm Model No
|
Pulse Valve
Model No
|
Pulse Valve
Port Size
|
Diaphragm
Material
|
|
M25
|
FP20, FM20, FP25, FM25, DP20, DM20, DP25, DM25, EP25, EM25, SQP20, SQM20, SQP25, SQM25, FDP20, FDM20, FDP25, FDM25
|
3/4'', 1''
|
NBR (standard)
FKM (optional)
|
|
M40 & M25
|
FP40, FM40, DP40, DM40, EP40, EM40
|
1-1/2''
|
|
|
M50 & M25
|
FP50, FM50, FP55, FM55, SQP50, SQM50, SQP55,
SQM55, SQP60, SQM60, SQP65, SQM65
|
2'', 2-1/2''
|
|
|
M75 & M25
|
FP65, FM65, SQP75, SQM75
|
2-1/2'', 3''
|
|
|
M100 & M25
|
SQP100, SQM100
|
3-1/2'', 4''
|
Our Production:
Related Products:
|
|
|
|
| Solenoid Coil | Solenoid Armature | Pulse Valve | Pulse Controller |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Echo
Tel: +8613454729544
