| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | GRN102F |
| Minimum Order Quantity: | 4pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 50000pcs per month |
| Product Name: | Pressure Reducing Valve | Port Size: | 4'' |
|---|---|---|---|
| Pipe Connection: | Flange | Orifice Size: | 100mm |
| Flow Rate: | 100m³/h | Body Material: | Plastic (Nylon) |
| Diaphragm Material: | NBR (Standard), EPDM (Optional) | Input Pressure: | 1 To 10 Bar |
| Output Pressure: | 0.8 To 6.5 Bar | ||
| Highlight: | Water Pressure Reducing Valve,Pressure Reducing Irrigation Valve,Pressure Reducing Valve 4'' |
||
4'' Flange Manual Water Pressure Reducing Irrigation Valve
This is a pressure reducing valve for irrigation, that reduces higher upstream pressure to lower constant downstream pressure, diaphragm pilot operated, 1-1/4'' to 6'' port size, flanged or threaded end connection types. If you have any demands or interests, pls just contact us!
Technical Data:
|
Model No
|
GRN32F
|
GRN40F
|
GRN50F
|
GRN65F
|
GRN75F
|
GRN102F
|
GRN127F
|
GRN152F
|
|
Pipe Connection
|
Flange
|
|||||||
|
Orifice Size
|
32mm
|
40mm
|
50mm
|
65mm
|
80mm
|
100mm
|
125mm
|
150mm
|
|
Port Size
|
1-1/4''
|
1-1/2''
|
2''
|
2-1/2''
|
3''
|
4''
|
5''
|
6''
|
|
Max. Flow Range
(m³/h)
|
12
|
18
|
50
|
55
|
60
|
100
|
110
|
180
|
|
Inlet Pressure
|
1 to 10 bar
|
|||||||
|
Outlet Pressure
|
0.8 to 6.5 bar
|
|||||||
|
Body Material
|
Plastic (Nylon)
|
|||||||
|
Diaphragm Material
|
NBR (Standard), EPDM (Optional)
|
|||||||
GRN102F Dimension:
Our Production:
FAQ: How to use?
1. Installed this valve to pipe line according to the arrow pointed to inlet and outlet. O-ring should be used if installed with flange.
2. Ensure all connectors & adaptors are well tighten and no leakage. Or should be fixed again.
3. Operating:
a. Turn the three way control valve to "AUTO".
b. Install a pressure gauge at the outlet of pressure reducing valve.
c. Loose the locking nut at the top of pilot.
d. Adjust the screw until the pressure up to requirement.
e. Tighten locking nut.
4. For closing valve, turn the three way control valve to "CLOSE".
