Place of Origin: | Ningbo, China |
Brand Name: | BRANDO |
Certification: | CE, ISO |
Model Number: | BPV28 |
Minimum Order Quantity: | 200pcs |
---|---|
Price: | Negotiation |
Packaging Details: | Blister Case, Carton, Pallet |
Delivery Time: | about 10 to 20 working days |
Payment Terms: | T/T, PayPal, Western Union |
Supply Ability: | 10000pcs per month |
Product Name: | Solenoid Valve | Inlet Size: | φ18.5 Barb |
---|---|---|---|
Outlet Size: | φ16.8 Barb | Body Material: | Plastic |
Working Medium: | Water | Max Pressure: | 0.2 Bar |
Flow Rate: | 3L/min | Insulation Class: | E |
Wire Length: | 545mm | Noise: | ≤45db |
Fluid Temperature: | 0 To +40℃ | Ambient Temperature: | 0 To +60℃ |
Function: | 2 Way Normally Closed | Voltage: | 24VDC, 36VDC, 110VAC, 220VAC |
Highlight: | Floor Scrubber Solenoid Valve,Floor Cleaner Solenoid Valve,Water Plastic Solenoid Valve |
Water Plastic Solenoid Valve For Tennant Floor Scrubber 24VDC 36VDC 110VAC 220VAC
This is a plastic water solenoid valve, popularly used in floor cleaning machines, like floor scrubber, floor cleaner, etc. The valve's max pressure is 0.2 bar, the flow rate is 3L/min, the standard wire length is 545mm, and the standard voltage is 24VDC, 36VDC, 110VAC, 220VAC, other wire lengths and voltage can be customized. If you have demands, pls contact us!
Technical Data:
Main Dimension:
Standard Packaging:
Our Production:
FAQ:
Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of applications.
Question 2: How can you tell if your solenoid is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out coil, you need to troubleshoot the valve solenoids.
Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, orifice size, temperature, pressure, voltage, response time and certification required for your application.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
