Name: K4502 CA45T RCA45DD 1-1/2" Aluminum Pulse Jet Valve Nitrile Diaphragm Repair Kit
Brand: Brando
SKU: G45
Rating: 4.6 (107 reviews)

Home Products Diaphragm Repair Kit

K4502 CA45T RCA45DD 1-1/2" Aluminum Pulse Jet Valve Nitrile Diaphragm Repair Kit

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE, ISO
Model Number:	G45

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	negotiation
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000PCS PER MONTH

Contact Now

Detailed Product Description

Diaphragm Material:	Nitrile/Buna	Sealing Gasket Material:	Nitrile/Buna
Suitable Valve Number:	CA45, RCA45 MM/F/T/DD Series	Diaphragm Outer Distance:	124mm
Center Distance:	112mm	Sealing Gasket OD:	68mm
Sealing Gasket ID:	31.5mm	Spring:	With
Air Hole:	With	Packaging:	Individual Sealed
Size:	1-1/2'
High Light:	Goyen K4502 M2162 , K4502 Diaphragm Set , Nitrile Diaphragm Repair Kit

K4502 CA45T RCA45DD 1-1/2" Aluminum Pulse Jet Valve Nitrile Membrane Repair Kit

Products Description

Main Features:
1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change
fluid pressure into drive power.

2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction.
This layer of fabric give tremendous design flexibity.

3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or
require extremely high-strength.

4. Facbric-reinforced diaphragms advantages:
* No leakage * No Lubrication * No Breakaway Force
* No Friction * Wide Pressure Ranges * High Strength
* Low Cost * Simple Design * Versatility

5. EPDM, FKM all available.

Main Dimension

K4502, K4503, K4504, K4522

Diaphragm Reference Number

Ordering Number of Diaphragm For Goyen Pulse Valve:

Pulse Valve Model		NBR Diaphragm Model	FKM Diaphragm Model	Low Temprature Diaphragm Model
RCA10-6T		K1001	K1002	/
CA20T	RCA20T	K2000 (M1204B) K2002 (M764)	K2007	/
CA20DD	RCA20DD	K2000 (M1204B) K2002 (M764)	K2007	/
CA25T	RCA25T	K2501 (M1183B) K2502 (M736)	K2503 (M1887)	K2504
CA25DD	RCA25DD
CAC25FS	RCA25FS
CA25MM	RCA25MM
CA32T	RCA32T	K2500 (M1183) K2522 (M736)	K2503 (M1887)	/
CA35T	RCA35T	K3500 (M1581)	K3501	K3502 (M1591)
CA40T	RCA40T	K4000 (M1182)	K4007	/
CA40MM	RCA40MM	K4000 (M1182)	K4007	/
CA45T	RCA45T	K4502 (M2162) K4504 (M2187)	K4503	K4522
CA45DD	RCA45DD
CA45FS	RCA45FS
CA40MR	RCA40MR
CA50T	RCA50T	K5004 (M1638A) K5005 (M1639A)	K5000	/
CA62T	RCA62T	K5004 (M1638A) K5005 (M1639A)	K5000	/
CA76T	RCA76T	K7600	K7601	/
CA76MM	RCA76MM
CA76MR	RCA76MR
CA102MM	RCA102MM	K10200	K10201	/
CA62MR	RCA62MR	K7604	K7602	/
RCA20M		K2003 (M1174B)	/	/
RCAC20T3, ST3, DD3, FS3		K2016	K2017	/
RCAC25T3, DD3, FS3		K2529	K2530
RCAC25FH3		K2531	/	/

Pulse Valve Model		Shockwave Diaphragm Model	FKM Diaphragm Model	/
RCAC20T4, ST4, DD4, FS4		K2034	K2033	/
RCAC25T4, ST4, DD4, FS4		K2546	K2551	/
RCAC25FH3		K2545	/	/
RCAC25T3, DD3, FS3		K2549	/	/
