SCG353A051 2.5'' Threaded Right Angle 353 Series Solenoid Pulse Jet Valve

SCG353A051 2.5'' Threaded Right Angle 353 Series Solenoid Pulse Jet Valve

  • SCG353A051 2.5'' Threaded Right Angle 353 Series Solenoid Pulse Jet Valve
  • SCG353A051 2.5'' Threaded Right Angle 353 Series Solenoid Pulse Jet Valve
SCG353A051 2.5'' Threaded Right Angle 353 Series Solenoid Pulse Jet Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: SCG353A051
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Type: Right Angle Type Diaphragm Valve Power: Solenoid
Media: Air Port Size: 2'' Inch
Structure: Diaphragm Body Material: Aluminum Alloy
Diaphragm Material: NBR(Common), FKM(Available) Number Of Diaphragm: 2
Pressure: 0.1 To 0.8MPa Temperature: -25 To +80℃
High Light:

2.5'' Pulse Valve

,

SCG353A051 Pulse Jet Valve

,

353 Series Solenoid Pulse Jet Valve

SCG353A051 2.5'' Threaded Right Angle 353 Series Solenoid Pulse Jet Valve



Products Description
Working principle of 353 series dust collector valves:
The two chambers of the dust collector valves are connected together through an air passage (smaller in diameter than the pilot valve orifice when so equipped). When the orifice is opened, the air in the upper chamber is exhausted, at a much faster rate than the speed of which air enters through the air passage, therfore the air pressure in the upper chamber drops significantly. As this occurs, the higher air pressure in the lower chamber pushes the diaphragm up allowing a large volume of air through to the bottom chamber and its outlet connected to the dust collector bags. This sudden burst of air inflates the filter bags or "pops" the filter bags so as to shake loose accumulated material on the outside of each filter bag. When the orifice closes, the pressure in the upper and lower chambers equalize and the diaphragm returns to its original position, aided by the force of a return spring. The dust collector valves are important components to keep dust collector systems operating efficiently and effectively.
Main Dimension
SCG353A051 2.5'' Threaded Right Angle 353 Series Solenoid Pulse Jet Valve 0



SCG353A051

353 Series Pulse Jet Valves
Model
SCG353A043
SCG353A044
SCG353A047
SCG353A050
SCG353A051
Port Size
3/4''
1''
1 1/2''
2''
2 1/2''
Voltages
24VDC, 24VAC, 110VAC, 220VAC
Diaphragm Number
1
2
Working Pressure Range
0.35 to 8.5 bar
Diaphragm Material
TPE, NBR, FKM
Fluids
Air
Valve Structure
Right Angle, Threaded

Our Production
SCG353A051 2.5'' Threaded Right Angle 353 Series Solenoid Pulse Jet Valve 1
Packing&Shipping
SCG353A051 2.5'' Threaded Right Angle 353 Series Solenoid Pulse Jet Valve 2



Internal Box

SCG353A051 2.5'' Threaded Right Angle 353 Series Solenoid Pulse Jet Valve 3



Carton

SCG353A051 2.5'' Threaded Right Angle 353 Series Solenoid Pulse Jet Valve 4



Pallet



OEM ODM Service



Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!

Tag:

Dust Collector Pulse Valve,

Dust Collector Diaphragm Valve,

Diaphragm Pulse Valve
