| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE, ISO |
| Model Number: | DMF-Y-62S |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4 to 7 days |
| Payment Terms: | T/T, Western Union, PayPal |
| Supply Ability: | 10000 pcs per month |
| Port Size: | 2 1/2'' | Valve Type: | Submerged |
|---|---|---|---|
| Valve Operation: | Diaphragm Pilot Operated | Diaphragm Material: | NBR, FKM |
| Coil Voltages: | 24VDC, 24VAC, 110VAC, 220VAC | Working Pressure Range: | 0.1 To 0.8 MPa |
| Body Material: | Aluminum Alloy | Application: | Dust Collector |
| High Light: | 2.5'' Embedded Pulse Valve,BFEC DMF-Y-62S Pulse Valve,SBFEC Type |
||
BFEC DMF-Y-62S 2.5'' Embedded Pulse Jet Valve For Dust Collector Baghouse
Pulse jet valves are indirect operated solenoid valves especially designed for dust collector systems. When the solenoid is energized, trapped air above a diaphragm is quickly exhausted causing a high pressure difference across the diaphragm. Thereby the diaphragm is suddenly opened. When the solenoid is de-energized, air escapes through a hole to the chamber above the diaphragm which balances the pressure and instantly closes the valve.
The fast opening and closing of the valve is of great importance for effective cleaning of filters and economical consumption of compressed air. This is made possible by keeping the weight of the moving parts small and therefore having a small inertia. These valves have very high kV values.
Dimension of DMF-Y-62S Pulse Jet Valve:
More BFEC Pulse Valves for you to choose:
|
|
|
|
| Right Angle Type | Quick Mount Type | Straight Through Type | Submerged Type |
|
|
|
|
| Diaphragm | Solenoid Coil | Solenoid Armature | Pulse Controller |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
