CA62MM 2-1/2'' Goyen Type Submerged Pulse Jet Valve For Dust Collector
The switching performance of the CA62MM Goyen Type Pulse Jet Valve directly affects the blowing effect and efficiency of the cleaning system. It mainly tests the CA62MM Pulse Jet Valve by the test equipment that responds to parameters such as response time, opening time, blowing time, closing time and peak pressure. Switch performance test and record the switch performance curve.
Goyen Type Pulse Jet Valve:
1. Right angle Pulse Jet Valve: CA15T, CA20T, CA25T, CA35T, CA45T, CA50T, CA62T, CA76T, RCA20T, RCA25T, RCA45T, RCA50T, RCA62T, RCA76T
2. Dresser Nut Pulse Jet Valve: CA20DD, CA25DD, CA45DD, RCA20DD, RCA25DD, RCA45DD
3. Immersion Pulse Jet Valve: CA50MM, CA62MM, CA76MM, CA102MM, RCA50MM, RCA62MM, RCA76MM, RCA102MM
4. Flanged Pulse Jet Valve: CAC25FS, CAC45FS, RCA25FS, RCA45FS
5. Remote solenoid valve: RCA3D2, RCA3DS
Typical Applicatoins of Dust Collector Valve:
1. Coal fired boiler dust collectors for power station applications.
2. Process and kiln collectors in cement plants.
3. Long filter or pleated filterbag technology, ideal for high pressure pulsing of 8m and larger filter bags. Equally suitable for high cloth areas of pleated filter bags.
4. Low pressure pulsing applications. The 25% increase in flow capacity will allow lower cleaning system tank pressures than previously achieved in like for like applications.
Technical data of Full Immerse Pulse Jet Valve:
Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.
|
Model No.
|
BB12039508
|
|
Ref No.
|
QR
|
|
Voltage
|
AC110V, AC220V, DC12V, DC24V
|
|
Connection
|
DIN 43650A
|
|
Other can be customized, please contact us.
|
|
Model No.
|
BAPC212050501
|
|
Ref No.
|
K0380
|
|
NC/NO
|
NC
|
|
2 Way or 3 Way
|
2Way
|
|
Other can be customized, please contact us.
|
|
Model No.
|
G50
|
|
Ref No.
|
K5000
|
|
Replace For
|
CA50T
|
|
Mounting Hole Dia.
|
8.5mm
|
|
Sealing Disc OD
|
103mm
|
|
Ref. Number
|
CA62MM
|
|
Working Pressure
|
0.3~0.8Mpa
|
|
Voltage
|
24V DC, 110V AC, 220V AC
Other voltages can be customized.
|
|
Diaphragm Nos
|
2
|
|
Port Size
|
G2-1/2''
|
|
Other requirement please contact.
|
