| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | ISO, CE |
| Model Number: | M/D40 (AE40) |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100000 sets per month |
| Product Name: | Pulse Valve Diaphragm | Diaphragm Material: | TPE |
|---|---|---|---|
| Fitted Pulse Valve Port: | 1 1/2'' | Fitted Pulse Valve Model: | AE1440B, AE2440B, AE1440R, AE2440R |
| High Light: | 1.5'' M/D40 TPE Diaphragm,Pulse Jet Valve M/D40 TPE Diaphragm,Autel M/D40 Membrane |
||
M/D40 TPE Diaphragm For 1.5'' Autel Type Dust Collector Pulse Jet Valve
The diaphragm is the most important part of the pulse valve. When the pulse valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pulse valve is de-energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the pulse valve.
Options for your customization:
1. Diaphragm Material: TPE, NBR, EPDM, FKM
2. Seat Material: Nylon, Rubber, PTFE
3. Diaphragm Color: Black, White, Red, Green, etc
4. Diaphragm Size: We can make it as same as your drawing
5. Packaging: We can provide you custom plastic bag with low MOQ
Ordering Code of Diaphragm For AUTEL Pulse Valve:
|
Diaphragm
Order Code
|
Diaphragm Reference No |
Pulse Valve
Model No
|
Pulse Valve
Port Size
|
Diaphragm
Material
|
|
AE18
|
M/D20
|
AE1818B, AE2818B
AE1822B, AE2822B
|
3/4'', 1''
|
TPE (Standard)
FKM+PTFE (High Temperature)
|
|
AE25
|
M/D25
|
AE1825B, AE2825B
AE1825R, AE2825R
|
1''
|
|
|
AE40
|
M/D40
|
AE1440B, AE2440B
AE1440R, AE2440R
|
1-1/2''
|
|
|
AE50
|
M/D50
M/D60
|
AE1450B, AE2450B
AE1460B, AE2460B
|
2'', 2-1/2''
|
|
|
AE75
|
M/D75
|
AE1475I12, AE2475I12
|
3''
|
Main Dimension of M/D40 Diaphragm:
 |
|
| Main Diaphragm | Secondary Diaphragm |
Product Video of M/D40 Diaphragm:
Pictures of Solenoid Valve Membrane Production:
