| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | BCKH-NSC-Z10, BCKH-NSC-Z6, BCKH-NSC-Z4, BCKH-NSC-Z8 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Flow Control Fitting | Tube OD (Inch): | 1/8", 1/4", 3/8", 1/2", M5X0.8, M6X1 |
|---|---|---|---|
| Tube OD (Mertric): | 4mm, 6mm, 8mm, 10mm, 12mm | Color: | Blue, Black, Gray |
| Material: | Plastic, Brass, Aluminum | Medium: | Compressed Air |
| Working Pressure Range: | 0 To 1.0 MPa | Working Temperature: | 0 To +60℃ |
| High Light: | Push On Tube Pneumatic Hose Fitting,Air Flow Speed Control Fitting,Brass Metal Pneumatic Hose Fitting |
||
Brass Metal Air Flow Speed Control Push To Connect Pneumatic Hose Fitting
Flow control valves are used to reduce the rate of flow in a section of a pneumatic circuit, resulting in a slower actuator speed. Unlike a needle valve, a flow control valve regulates air flow in only one direction, allowing free flow in the opposite direction.
Specifications of BCKH-NSC-Z Pneumatic Air Flow Speed Fittings:
|
Model No
|
R
|
φD
|
L1
|
L
|
L'
|
S
|
|
BCKH-NSC-Z4
|
M5X0.8
|
6
|
6
|
24
|
29
|
S8
|
|
M6X1
|
6
|
24
|
29
|
S8
|
||
|
ZG1/8''
|
8
|
28
|
35
|
S12
|
||
|
ZG1/4''
|
9
|
29
|
42
|
S15
|
||
|
ZG3/8''
|
10
|
31
|
46
|
S19
|
||
|
ZG1/2''
|
12
|
33
|
52
|
S24
|
||
|
BCKH-NSC-Z6
|
M5X0.8
|
8
|
6
|
27
|
29
|
S8
|
|
M6X1
|
6
|
27
|
29
|
S8
|
||
|
ZG1/8''
|
8
|
31
|
35
|
S12
|
||
|
ZG1/4''
|
9
|
29
|
42
|
S15
|
||
|
ZG3/8''
|
10
|
31
|
46
|
S19
|
||
|
ZG1/2''
|
12
|
34
|
52
|
S24
|
||
|
BCKH-NSC-Z8
|
ZG1/8''
|
10
|
8
|
33
|
38
|
S12
|
|
ZG1/4''
|
9
|
32
|
45
|
S15
|
||
|
ZG3/8''
|
10
|
34
|
48
|
S19
|
||
|
ZG1/2''
|
12
|
36
|
52
|
S24
|
||
|
BCKH-NSC-Z10
|
ZG1/8''
|
12
|
8
|
36
|
38
|
S12
|
|
ZG1/4''
|
9
|
35
|
45
|
S15
|
||
|
ZG3/8''
|
10
|
35
|
48
|
S19
|
||
|
ZG1/2''
|
12
|
37
|
52
|
S24
|
List of All Pneumatic Air Flow Speed Fittings:
Choosing the Right Fittings for Your Pneumatic System:
Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.
Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
