Brass Male Banjo Connector Push On Pneumatic Hose Fitting 1/8" 1/4" 3/8" 1/2"

Brass Male Banjo Connector Push On Pneumatic Hose Fitting 1/8" 1/4" 3/8" 1/2"

  • Brass Male Banjo Connector Push On Pneumatic Hose Fitting 1/8" 1/4" 3/8" 1/2"
Brass Male Banjo Connector Push On Pneumatic Hose Fitting 1/8" 1/4" 3/8" 1/2"
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: BCKH-JJ-Z4,BCKH-JJ-Z2.5,BCKH-JJ-Z6,BCKH-JJ-Z8,BCKH-JJ-Z10
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Plastic bag, Box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 10000000pcs per month
Contact Now
Detailed Product Description
Product Name: Pneumatic Hose Fitting Type: Male Banjo
Tube OD (Inch): 1/8", 1/4", 3/8", 1/2" Tube OD (Mertric): 4mm, 6mm, 8mm, 10mm, 12mm
Material: Brass Metal Working Pressure Range: 0 To 0.8 MPa
Working Temperature: 0 To +60 ℃ Connection: Push On
High Light:

Male Banjo Air Pneumatic Hose Fitting

,

Push On Tube Pneumatic Hose Fitting

,

Brass Metal Male Air Hose Fittings

Brass Male Banjo Connector Push On Pneumatic Hose Fitting 1/8" 1/4" 3/8" 1/2"



Push-to-connect fittings have ends that are designed to accept tubing by pushing it into the end. These fittings typically disconnect via some type of collar retraction. Push to connect fittings are convenient for sections of the system requiring frequent disconnection and reconnection. BRANDO offers Push to Connect fittings in a variety of configurations; Male Connectors, Female Connectors, 90° Elbows, Unions and Tees, in many sizes and a variety of materials; Brass, Nickel Plated Brass, Composite and Plastic. If you don’t see the pneumatic fitting you are looking for please contact us and we can find a push to connect fittings product inventory that is customized to your specific needs.



Technical data of Pneumatic Hose Fittings:

Material
Plastic / Brass
Threaded Connection
BSP
BSPP
Metric Thread
NPT
Working Pressure
0 to 0.8MPa
Connecting Tube
PA
PU
Connecting Diameter Tube
3mm, 4mm, 6mm, 8mm, 10mm, 12mm, 16mm (Outer Diameter)
Medium
Compressed Air
Working Temperature
~60℃



Specifications of Male Banjo Brass Pneumatic Hose Fittings:

                                 Brass Male Banjo Connector Push On Pneumatic Hose Fitting 1/8" 1/4" 3/8" 1/2" 0

Model No
D
R
L1
L
L'
S
BCKH-JJ-Z2.5
4
M5X0.8
6
28
18
8
BCKH-JJ-Z4
6
M5X0.8
6
29
18
8
M6X1
6
29
18
8
M8X1
7
29
24
12
ZG1/8''
8
29
25
12
ZG1/4''
10
29
28
15
ZG3/8''
11
31
34
19
ZG1/2''
12
33
37
24
BCKH-JJ-Z6
8
M5X0.8
6
27
18
8
M6X1
6
27
18
8
M8X1
7
27
24
8
ZG1/8''
8
31
25
12
ZG1/4''
10
29
28
15
ZG3/8''
11
31
34
19
ZG1/2''
12
34
37
24
BCKH-JJ-Z8
10
ZG1/8''
8
33
28
12
ZG1/4''
10
32
31
15
ZG3/8''
11
34
36
19
ZG1/2''
12
36
37
24
BCKH-JJ-Z10
12
ZG1/8''
8
36
28
12
ZG1/4''
10
35
31
15
ZG3/8''
11
35
36
19
ZG1/2''
12
37
37
24



Product Video of BRANDO Brass Pneumatic Hose Fittings:


List of All Push To Connect Brass Pneumatic Hose Fittings:

list



Choosing the Right Fittings for Your Pneumatic System:



Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.

Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting



Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
