PL Push To 90 Degree Male Elbow Pneumatic Hose Fitting 1/8" 1/4" 3/8" 1/2"

PL Push To 90 Degree Male Elbow Pneumatic Hose Fitting 1/8" 1/4" 3/8" 1/2"

Elbow Push To Connect Fittings:

Push to connect pneumatic elbow fittings are easy to use with quick push in capabilities. The elbow design allows for a 90° or 45° change of direction, with a variety of styles available for different pneumatic push-in fitting applications.

Elbow Push to Connect Fitting Styles:
90° Male Elbow
90° Male Elbow Extended
45° Male Elbow
90° Female Elbow
90° Union Elbow
90° Bulkhead Elbow
90° Male Elbow Banjo

Technical data of Pneumatic Hose Fittings:

Specifications of PL-G Male Elbow Pneumatic Hose Fittings:

List of All Push To Connect Pneumatic Hose Fittings:

Choosing the Right Fittings for Your Pneumatic System:

Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.

Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
