| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | PC4, PC6, PC8, PC10, PC12 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 1000000 pcs per month |
| Product Name: | Pneumatic Hose Fitting | Fitting Type: | Male Straight |
|---|---|---|---|
| Thread Size: | 1/8", 1/4", 3/8", 1/2", M5X0.8, M6X1 | Connecting Tube OD: | 4mm, 6mm, 8mm, 10mm, 12mm |
| Connection: | Push In | Pressure Range: | 0 To 0.8 MPa |
| High Light: | PC Pneumatic Hose Fitting,Push On Pneumatic Hose Fitting 6mm,Male Straight Air Hose Fitting 1/2" |
||
PC Push On Quick Connect Male Straight Pneumatic Hose Fitting 1/8" 1/4" 3/8" 1/2"
BRANDO's pneumatic hose fittings provide easy connection and disconnection tube without causing damage to the tube. BRANDO's pneumatic hose fittings are available in a variety of types, moulds, sizes and thread types to satisfy various metric and inch tube demands. BRANDO's pneumatic hose fittings could accommodate both metric size tubing and inch size tubing that are made from polyurethane, polyethylene and nylon.
Dimension of Male Straight Pneumatic Hose Fittings:
|
Model No
|
M
|
φD
|
L1
|
L
|
S
|
|
PC4-G
|
M5x0.8
|
4
|
4
|
22
|
12
|
|
M6X1
|
4
|
22
|
12
|
||
|
G1/8''
|
5
|
21
|
12
|
||
|
G1/4''
|
6
|
19
|
12
|
||
|
G3/8''
|
7
|
21
|
14
|
||
|
G1/2''
|
9
|
23
|
17
|
||
|
PC6-G
|
G1/8''
|
6
|
5
|
20
|
13
|
|
G1/4''
|
6
|
21
|
13
|
||
|
G3/8''
|
7
|
21
|
14
|
||
|
G1/2''
|
9
|
23
|
17
|
||
|
PC8-G
|
G1/8''
|
8
|
5
|
26
|
15
|
|
G1/4''
|
6
|
24
|
16
|
||
|
G3/8''
|
7
|
22
|
14
|
||
|
G1/2''
|
9
|
24
|
17
|
||
|
PC10-G
|
G1/8''
|
10
|
5
|
28
|
17
|
|
G1/4''
|
6
|
29
|
17
|
||
|
G3/8''
|
7
|
26
|
17
|
||
|
G1/2''
|
9
|
24
|
17
|
||
|
PC12-G
|
G1/8''
|
12
|
5
|
30
|
19
|
|
G1/4''
|
6
|
31
|
19
|
||
|
G3/8''
|
7
|
31
|
19
|
||
|
G1/2''
|
9
|
29
|
21
|
List of Push In Pneumatic Hose Fittings:
