| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | CA25T |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, PayPal |
| Supply Ability: | 10000 pcs per month |
| Port Size: | 1'' | Valve Series: | T Series |
|---|---|---|---|
| Valve Structure:: | Right Angle, Threaded Port | Coil Voltages: | 24VDC, 24VAC, 110VAC, 220VAC |
| Diaphragm Material: | NBR, FKM | Working Pressure Range: | 0.35 To 0.85 MPa |
| Highlight: | CA25T Goyen Pulse Jet Valve,Threaded Right Angle Pulse Jet Valve,Dust Collector Pulse Valves |
||
CA25T Goyen Type 1" Threaded Pulse Jet Valve For Dust Collector 24V 220V
Pulse Jet Valve, also called pulse diaphragm valve acts as a "switch" for compressed air in the dust collector system for bag filters.
CA T series pulse jet valve is a diaphragm valve whose inlet and outlet are at right angles and are directly controlled by electrical signals. The function of the pulse valve is to control the oil pressure in the oil circuit. It is generally installed in the main oil circuit or the back pressure oil circuit of the shock absorber, so as to reduce the oil pressure impact during gear shifting and lock unlocking and keep the equipment running in a stable state.
Different designs of pulse jet valves:
1. Threaded Type
2. Dresser Nut Type
3. Manifold Mount Type
4. Flanged Type
5. Straight Through Type
Specification of T Series Pulse Jet Valves:
|
Model No
|
CA15T
|
CA20T
|
CA25T
|
CA35T
|
CA45T
|
CA50T
|
CA62T
|
CA76T
|
|
Office Size
(mm)
|
15
|
20
|
25
|
35
|
45
|
50
|
62
|
76
|
|
Port Size
(Inch)
|
1/2''
|
3/4''
|
1''
|
1 1/2''
|
1 1/2''
|
2''
|
2 1/2''
|
3''
|
|
Diaphragm Number
|
1
|
2
|
||||||
|
Working pressure
|
0.35 to 0.85 MPa (5 to 125 PSI)
|
|||||||
|
Voltage
|
24VDC, 24VAC, 110VAC, 220VAC
|
|||||||
|
Diaphragm Material
|
NBR, FKM, EPDM
|
|||||||
|
Body Material
|
Aluminum Alloy
|
|||||||
|
Valve Structure
|
Right Angle (Outlet is at 90° to Inlet), Threaded Port
|
|||||||
Dimension of CA25T Pulse Jet Valve:
Ordering Code of T Series Pulse Jet Valve:
Video of CA25T Pulse Jet Valve:
More Goyen Type Pulse Jet Valves for you to choose:
|
|
|
|
| T Series | DD Series | FS Series | MM Series |
|
|
|
|
| RCA Series | Solenoid Coil | Solenoid Armature | Diaphragm |
