Name: 4V330C-10 Airtac Type Double Pneumatic Solenoid Valve 5 Way 3 Position 24V 220V
Brand: BRANDO
SKU: 4V330C-10
Rating: 4.8 (197 reviews)

Home Products Pneumatic Solenoid Valve

4V330C-10 Airtac Type Double Pneumatic Solenoid Valve 5 Way 3 Position 24V 220V

Product Details:

Place of Origin:	China
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	4V330C-10

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Plastic bag, Box, Carton, Pallet
Delivery Time:	4 to 7 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	200000 pcs per month

Contact Now

Detailed Product Description

Product Name:	Pneumatic Solenoid Valve	Valve Type:	5/3 Way
Port Size:	In=Out=3/8'' Exhaust=1/4''	Working Fluid:	Air (to Be Filtered By 40 μm Filter Element
Pressure Range:	0.15 To 0.8 MPa (21 To 114 Psi)	Max Pressure Resistance:	1.5 MPa (215 Psi)
Body Material:	Aluminum Alloy	Coil Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
High Light:	Airtac Valve 4V330C-10 , Pneumatic Solenoid Valve 5/3 Way , 24vdc Pneumatic Solenoid Valve

4V330C-10 Airtac Type Double Pneumatic Solenoid Valve 5 Way 3 Position 24V 220V

Pneumatic directional control solenoid valves are used in pneumatic systems to direct or stop the flow of compressed air or oil to their appliances. They are probably the most used elements in pneumatic systems and can be used for example to actuate a cylinder, a larger industrial valve, or air tools. The valves can have two or more ports and fulfill various circuit functions. The function and behavior of the valve can be indicated by a symbol. The symbol however doesn't explain the construction of the valve. Pneumatic directional control solenoid valves can be actuated by different means, such as manual actuation or solenoid actuation.

Data of 4V300 Series Pneumatic Solenoid Valves:

Model	4V310-08 4V320-08	4V330C-08 4V330E-08 4V330P-08	4V310-10 4V320-10	4V330C-10 4V330E-10 4V330P-10
Fluid	Air(to be filtered by 40 μ m filter element)
Acting	Internal pilot or external pilot
Port Size	In=Out=Exhaust=1/4''		In=Out=3/8'' Exhaust=1/4''
Orifice Size	25.00 mm2 (Cv=1.40)	18.00 mm2 (Cv=1.00)	30.00 mm2 (Cv=1.68)	18.00 mm2 (Cv=1.00)
Valve Type	5 port 2 position	5 port 3 position	5 port 2 position	5 port 3 position
Operating Pressure	0.15~0.8MPa(21~114psi)
Proof Pressure	1.5MPa(215psi)
Temperature ℃	-20~70
Material of Body	Aluminum alloy
Max. frequency	4 cycle/sec	4 cycle/sec	4 cycle/sec	4 cycle/sec
