8mm 1/4'' Female Straight Pneumatic Hose Fitting Push In To Connect

8mm 1/4'' Female Straight Pneumatic Hose Fitting Push In To Connect

  • 8mm 1/4'' Female Straight Pneumatic Hose Fitting Push In To Connect
8mm 1/4'' Female Straight Pneumatic Hose Fitting Push In To Connect
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: PCF
Payment & Shipping Terms:
Minimum Order Quantity: 10 pcs
Price: Negotiation
Packaging Details: Plastic bag, Box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000000pcs per month
Contact Now
Detailed Product Description
Product Name: Pneumatic Hose Fitting Fitting Type: Female Straight
Color: Black, Blue, Red, White Material: Plastic, Brass
Thread Size: M5X0.8, M6X1, 1/8", 1/4", 3/8", 1/2" Connecting Tube OD: 4mm, 6mm, 8mm, 10mm, 12mm
Connection: Push In Pressure Range: 0 To 0.8 MPa
High Light:

Female Straight Pneumatic Fittings

,

Female Straight Pneumatic Fitting 1/4''

,

Push Pneumatic Hose Fitting

8mm 1/4'' Female Straight Pneumatic Hose Fitting Push In To Connect



BRANDO's pneumatic hose fittings provide easy connection and disconnection tube without causing damage to the tube. BRANDO's pneumatic hose fittings are available in a variety of types, moulds, sizes and thread types to satisfy various metric and inch tube demands. BRANDO's pneumatic hose fittings could accommodate both metric size tubing and inch size tubing that are made from polyurethane, polyethylene and nylon.



Dimension of Female Straight Pneumatic Hose Fittings:

8mm 1/4'' Female Straight Pneumatic Hose Fitting Push In To Connect 0

Model No
M
φD
D1
L1
L
S
PCF4
M5x0.8
4
11
6
22
12
M6X1
6
22
12
G1/8''
7
23
13
G1/4''
8
24
16
G3/8''
9
25
19
G1/2''
10
26
24
PCF6
M5X0.8
6
13
6
23
13
M6X1
6
23
13
G1/8''
7
24
13
G1/4''
8
25
16
G3/8''
9
26
19
G1/2''
10
27
24
PCF8
G1/8''
8
15
7
26
15
G1/4''
8
27
16
G3/8''
9
28
19
G1/2''
10
29
24
PCF10
G1/8''
10
17
7
28
17
G1/4''
8
29
17
G3/8''
9
30
19
G1/2''
10
31
24
PCF12
G1/8''
12
21
7
30
21
G1/4''
8
31
21
G3/8''
9
32
21
G1/2''
10
33
24
