1-1/4'' PTFE Plastic Solenoid Valve Acid Alkali Resistant 24V 220V

1-1/4'' PTFE Plastic Solenoid Valve Acid Alkali Resistant 24V 220V

  • 1-1/4'' PTFE Plastic Solenoid Valve Acid Alkali Resistant 24V 220V
1-1/4'' PTFE Plastic Solenoid Valve Acid Alkali Resistant 24V 220V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: PTFE
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Function: 2 Way Normally Closed Port Size: 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2'', 2 1/2''
Orifice Size: 15mm, 20mm, 25mm, 32mm, 40mm, 50mm, 60mm Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Fluids: Acid & Alkali (Gas, Liquid) Valve Body Material: PTFE ()
Seal Material: FKM, EPDM Working Pressure Range: 0.01 To 0.6 MPa
High Light:

1-1/4'' Plastic Solenoid Valve

,

PTFE Plastic Solenoid Valve

,

Anti- Corrosion Valve

1-1/4'' PTFE Plastic Solenoid Valve Acid Alkali Resistant 24V 220V

Feature of Valve Material:

1. Material of valve body, cap, core and pole: brand new PTFE resin.
2. Sealing material: high tech sealing part, anti-corrosion for strong acid, strong alkali, strong oxidant and organic solvent.
3. The unique patent design piston to replace the membrane sheets.
4. Fluid and matel parts (pluger,spring) have no direct contact, that means the fluid only contact with the plastics parts such as CPVC,
5. PTFE, O-ring, which is anti-corrosive absolutely .
6. Push-in tyoe sealing structure,more reliable sealing properties.



Outstanding Chemicals Resistance:
1. PTFE is always stable almost for any chemicals such as strong acid (98% H2SO4), HNO3, HCL and its weights and performance has no any change even if it is boiled in the aqua fortis.
2. PTFE has the properties of no damping and FR as well as it is also stable for oxidant and UV light, therefore it is climate resistance, anti-oxidant, anti-stain and fragilization resistance.
3. No pollution, no toxic, no odor, high purities and chemical inerthness, it will have no any effect on the fluid medium.
4. Wide Temperature application range: -50℃ to +200℃.



Technical Data of Body Solenoid Valve:

Model
PTFE-15
PTFE-20
PTFE-25
PTFE-32
PTFE-40
PTFE-50
PTFE-65
Port Size
1/2''
3/4''
1''
1 1/4''
1 1/2''
2''
2 1/2''
Orifice Size
15mm
20mm
25mm
32mm
40mm
50mm
60mm
Cv Value
4
5.5
13
17
25
40
62
Medium
Acid & Alkali (Gas, Liquid)
Working Pressure
0.01 to 0.6MPa
Working Temperature
Max. +180℃
Seal Material
FKM, EPDM
Voltage
220VAC
15W
Start: 200W
Keep: 5W
Start: 350W
Keep: 10W
24VDC
16W
28W
Start: 75W
Keep: 25W


Main Dimension of PTFE Body Solenoid Valve:

1'' Anti Corrosive Solenoid Valve PTFE  Body 24V DC 220V AC 0

Model
Dimension
D
H
E
A
M
L
K
F
PTFE-15
70
127
56.5
18.5
M5
14
92
58
PTFE-20
80
136
70.5
20
M6
10
92
67
PTFE-25
95
145
78
25
M6
12
92
75
PTFE-32
120
200
110
31
M8
20
94
98
PTFE-40
130
220
113
33.5
M8
18
94
106
PTFE-50
150
249
140
43
M10
20
94
116
PTFE-65
180
262
152
49
M10
25
94
116



Brando Solenoid Valve Factory Production Video:



More PTFE Body Solenoid Valves for you to choose:

1-1/4'' PTFE Plastic Solenoid Valve Acid Alkali Resistant 24V 220V 1 1-1/4'' PTFE Plastic Solenoid Valve Acid Alkali Resistant 24V 220V 2 1-1/4'' PTFE Plastic Solenoid Valve Acid Alkali Resistant 24V 220V 3
