DN25 1'' Thread PTFE Plastic Solenoid Valve Anti Corrosive 24V 220V

DN25 1'' Thread PTFE Plastic Solenoid Valve Anti Corrosive 24V 220V

  • DN25 1'' Thread PTFE Plastic Solenoid Valve Anti Corrosive 24V 220V
DN25 1'' Thread PTFE Plastic Solenoid Valve Anti Corrosive 24V 220V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: PTFE
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: Anti Corrosion Solenoid Valve Function: 2 Way, Normally Closed
Port Size: 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2'', 2 1/2'' Orifice Size: 15mm, 20mm, 25mm, 32mm, 40mm, 50mm, 60mm
Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC Fluids: Acid & Alkali (Gas, Liquid)
Valve Body Material: PTFE () Seal Material: FKM, EPDM
Working Pressure Range: 0.01 To 0.6 MPa
High Light:

DN25 Plastic Solenoid Valve

,

PTFE Plastic Solenoid Valve

,

Anti Corrosive Valve

DN25 1'' Thread PTFE Plastic Solenoid Valve Anti Corrosive 24V 220V



ZCF15 2-way normally closed anti corrosion solenoid process valve is to control On/Off of air, inert gas, liquid, acid, alkali and salt water. This anti-corrosion solenoid valve has one 1/2'' inlet and one 1/2'' outlet port. Valve stays close when the coil is de-energized, and it opens when energized. Our unique piston design allows the fluid completely separate with the valve metal components. No corrosive fluid contacts the metal parts.


Technical Data of Body Solenoid Valve:

Model
PTFE-15
PTFE-20
PTFE-25
PTFE-32
PTFE-40
PTFE-50
PTFE-65
Port Size
1/2''
3/4''
1''
1 1/4''
1 1/2''
2''
2 1/2''
Orifice Size
15mm
20mm
25mm
32mm
40mm
50mm
60mm
Cv Value
4
5.5
13
17
25
40
62
Medium
Weak Acid & Alkali (Gas, Liquid)
Working Pressure
0.01 to 0.6MPa
Working Temperature
Max. +180℃
Seal Material
FKM, EPDM
Voltage
220VAC
15W
Start: 200W
Keep: 5W
Start: 350W
Keep: 10W
24VDC
16W
28W
Start: 75W
Keep: 25W


Main Dimension of PTFE Body Solenoid Valve:

1'' Anti Corrosive Solenoid Valve PTFE  Body 24V DC 220V AC 0

Model
Dimension
D
H
E
A
M
L
K
F
PTFE-15
70
127
56.5
18.5
M5
14
92
58
PTFE-20
80
136
70.5
20
M6
10
92
67
PTFE-25
95
145
78
25
M6
12
92
75
PTFE-32
120
200
110
31
M8
20
94
98
PTFE-40
130
220
113
33.5
M8
18
94
106
PTFE-50
150
249
140
43
M10
20
94
116
PTFE-65
180
262
152
49
M10
25
94
116
