| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | MD03-50, MD03-50M |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100000 sets per month |
| Product Name: | Pulse Valve Membrane | Membrane Material: | NBR |
|---|---|---|---|
| Seat Material: | Nylon | 1 Set: | 1pc Big Diaphragm, 1pc Small Diaphragm, 2pcs Springs |
| Fitted Pulse Valve Port: | 2'' | Fitted Pulse Valve Model: | TH-5450-B, TH-4450-B, TH-5450-M, TH-4450-M |
| High Light: | MD03-50 Diaphragm Repair Kit,MD03-50M Diaphragm Repair Kit,Taeha MD03-50 |
||
MD03-50 MD03-50M Diaphragm Repair Kit For Taeha TH-4450-B TH-4450-M
MD03-50, MD03-50M Diaphragm (Membrane) for Taeha pulse valve TH-5450-B, TH-4450-B, TH-5450-M, TH-4450-M; Pulse valve has just one moving part - diaphragm. The high speed operation besides saving of compressed air, helps to provide shock air wave for dislodging of dust from filter bags. High flow, long life and fast diaphragm action produce reliable and economical operation.
Ordering Code of Diaphragm For Taeha Pulse Valve:
|
BRANDO Model
|
Reference Number
|
Port Size
|
Fitted Pulse Valve Model
|
Color
|
Material
|
|
DH20
|
MD01-20
MD02-20
|
3/4''
|
TH-5820-B
TH-4820-B
TH-5825-B
TH-5820-C
TH-4820-C
|
Red & Green
|
NBR
|
|
DH25
|
MD01-25
MD02-25
|
1''
|
TH-4825-B
TH-5825-C
TH-4825-C
TH-5840-F
TH-4840-F
|
||
|
DH25M
|
MD01-25M
|
1''
|
TH-5825-M
|
||
|
DH40
|
MD01-40
MD02-40
MD03-40
|
1 1/2''
|
TH-5840-B
TH-5440-B
TH-4840-B
TH-4440-B
TH-5840-C
TH-5440-C
TH-4840-C
TH-4440-C
TH-5850-F
TH-5450-F
TH-4850-F
TH-4450-F
|
||
|
DH40M
|
MD03-40M
|
1 1/2''
|
TH-5440-M
TH-4440-M
|
||
|
DH50
|
MD03-50
|
2''
|
TH-5450-B
TH-4450-B
|
||
|
DH50M
|
MD03-50M
|
2''
|
TH-5450-M
TH-4450-M
|
||
|
DH60
|
MD03-60
MD04-60
|
2 1/2''
|
TH-5460-B
TH-4460-B
TH-5460-S
TH-4460-S
|
||
|
DH75
|
MD03-75
|
3''
|
TH-5475-B
TH-4475-B
|
||
|
DH75M
|
MD03-75M
|
3''
|
TH-5475-M
TH-4475-M
|
Main Dimension of MD03-50, MD03-50M Diaphragm:
Main Diaphragm:
Secondary Diaphragm:
Pictures of Solenoid Valve Membrane Production:
More Products For Taeha Pulse Valve for you to choose:
|
|
|
|
| Valve Diaphragm | Solenoid Coil | Solenoid Armature | Pulse Controller |
