| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | BC-24 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 200000 pcs per month |
| Product Name:: | Pulse Controller | Max Output Channel Number: | 24 Line |
|---|---|---|---|
| Input Voltage: | 220VAC | Output Voltage: | 24VDC, 220VAC |
| Pulse Frequency: | 1 To 30 Seconds | Pulse Durtion: | 0.03 To 0.2 Seconds |
| High Light: | Pulse Valve Controller Board,Sequential Controller For Dust Collector,Dust Collector Electronic Pulse Controller |
||
24 Line Pulse Valve Sequential Controller Board For Dust Collector
Pulse valve controller is the main control equipment in the dust cleaning system of pulse jet dust collector. Its output signals control the solenoid valves, which spray and inject compressed air to clear dust from the filter elements in sequence. The controller output pulse interval and pulse width are set according to the dust cleaning requirement of the dust collector to ensure that the system resistance remains within the set range.
Video of 24 Channel Pulse Controller:
Technical Data of Pulse Valve Controller:
|
Model
|
BC-08
|
BC-10
|
BC-12
|
BC-20
|
BC-24
|
BC-30
|
BC-36
|
BC-56
|
BC-64
|
|
Output Lines NO.
|
1-8
|
1-10
|
1-12
|
1-20
|
1-24
|
1-30
|
1-36
|
1-56
|
1-64
|
|
Input Voltage
|
220VAC, Other voltage can be customized
|
||||||||
|
Output Voltage
|
24VDC, 220VAC, Other voltage can be customized
|
||||||||
|
Pulse Frequency
|
1 to 30 Seconds
|
||||||||
|
Pulse Durtion
|
0.03 to 0.2 Seconds
|
||||||||
|
Working Environment
|
1. -25°C~+55°C
2. The relative humidity of the air does not exceed 85%
3. No serious corrosion gas and conductive dust
4. No violent vibration or shock
|
||||||||
Main Dimension of Pulse Valve Controller:
|
Output Lines
|
1-8
|
1-20
|
1-36
|
1-64
|
|
Dimension
|
115x135x65
|
160x160x95
|
230x150x90
|
248x188x105
|
Details Images of Pulse Valve Controller:
Brando Supply Dust Collector Parts:
| SBFEC Type Pulse Jet Valve | Goyen Type Pulse Jet Valve | ASCO Type Pulse Jet Valve | Turbo Type Pulse Jet Valve |
|
|
|
|
| Solenoid Valve Coil | Solenoid Valve Armature | Diaphragm | Controller |
|
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
