| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE, ISO |
| Model Number: | CA76T |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, PayPal |
| Supply Ability: | 10000 pcs per month |
| Port Size: | 3 Inch | Valve Series: | T Series |
|---|---|---|---|
| Valve Structure:: | Right Angle, Threaded Port | Coil Voltages: | 24VDC, 110VAC, 220VAC |
| Diaphragm Material: | Nitrile, Viton | Working Pressure Range: | 0.35 To 0.85 MPa |
| Highlight: | 3 Inch Pulse Jet Valve,Pulse Jet Valve T Series,Solenoid Pulse Valve For Dust Collector |
||
CA76T Goyen Type Pulse Jet Valve Right Angle Threaded T Series For Dust Collector
The right angle pulse jet valve is suitable for the installation and connection of the air bag and the spray pipe of the dust collector. The air flow is smooth and can provide the required pulse of ash cleaner. The diaphragm divides the solenoid pulse jet valve into the front and rear air chambers. When the compressed air is connected, the compressed air enters the rear air chamber through the orifice. At this time, the pressure of the rear air chamber will close the diaphragm assembly to the output port of the valve, which belongs to the closed state.
Specification of T Series Pulse Jet Valves:
|
Model No
|
CA15T
|
CA20T
|
CA25T
|
CA35T
|
CA45T
|
CA50T
|
CA62T
|
CA76T
|
|
Office Size
(mm)
|
15
|
20
|
25
|
35
|
45
|
50
|
62
|
76
|
|
Port Size
(Inch)
|
1/2''
|
3/4''
|
1''
|
1 1/2''
|
1 1/2''
|
2''
|
2 1/2''
|
3''
|
|
Diaphragm Number
|
1
|
2
|
||||||
|
Working pressure
|
0.35 to 0.85 MPa (5 to 125 PSI)
|
|||||||
|
Voltage
|
24VDC, 24VAC, 110VAC, 220VAC
|
|||||||
|
Diaphragm Material
|
NBR, FKM, EPDM
|
|||||||
|
Body Material
|
Aluminum Alloy
|
|||||||
|
Valve Structure
|
Right Angle (Outlet is at 90° to Inlet), Threaded Port
|
|||||||
Dimension of CA76T Pulse Jet Valve:
Ordering Code of T Series Pulse Jet Valve:
Video of CA76T Pulse Jet Valve:
More Goyen Type Pulse Jet Valves for you to choose:
|
|
|
|
| T Series | DD Series | FS Series | MM Series |
|
|
|
|
| RCA Series | Solenoid Coil | Solenoid Armature | Diaphragm |
