| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE, ISO |
| Model Number: | CA20T |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, PayPal |
| Supply Ability: | 10000 pcs per month |
| Port Size: | 3/4" | Valve Series: | T Series |
|---|---|---|---|
| Valve Structure:: | Right Angle, Threaded Port | Coil Voltages: | 24VDC, 110VAC, 220VAC |
| Diaphragm Material: | Nitrile, Viton | Working Pressure Range: | 0.35 To 0.85 MPa |
| Highlight: | T Series Pulse Jet Valve,3/4 Inch Pulse Jet Valve,Dust Collector Jet Pulse Valve |
||
CA20T Goyen Type Pulse Jet Valve Solenoid Threaded Right Angle T Series
Rectangular solenoid pulse valve electrical pulse signal disappeared, the electromagnetic pilot spring to the moving column immediately reset closed unloading hole, diaphragm chamber gas pressure and spring force to close the diaphragm channel, valve stop blowing. The damping hole on the diaphragm, when the pilot head moving column lifted the gas pressure unloading, play the role of damping airflow, when the unloading hole is closed, the pressure gas quickly filled to the back chamber, the diaphragm close the channel, stop blowing.
Technical Data of T Series Pulse Jet Valves:
|
Model No
|
CA15T
|
CA20T
|
CA25T
|
CA35T
|
CA45T
|
CA50T
|
CA62T
|
CA76T
|
|
Office Size
(mm)
|
15
|
20
|
25
|
35
|
45
|
50
|
62
|
76
|
|
Port Size
(Inch)
|
1/2''
|
3/4''
|
1''
|
1 1/2''
|
1 1/2''
|
2''
|
2 1/2''
|
3''
|
|
Diaphragm Number
|
1
|
2
|
||||||
|
Working pressure
|
0.35 to 0.85 MPa (5 to 125 PSI)
|
|||||||
|
Voltage
|
24VDC, 24VAC, 110VAC, 220VAC
|
|||||||
|
Diaphragm Material
|
NBR, FKM, EPDM
|
|||||||
|
Body Material
|
Aluminum Alloy
|
|||||||
|
Valve Structure
|
Right Angle (Outlet is at 90° to Inlet), Threaded Port
|
|||||||
Dimension of CA20T Pulse Jet Valve:
Ordering Code of T Series Pulse Jet Valve:
Video of CA20T Pulse Jet Valve:
More Goyen Type Pulse Jet Valves for you to choose:
|
|
|
|
| T Series | DD Series | FS Series | MM Series |
|
|
|
|
| RCA Series | Solenoid Coil | Solenoid Armature | Diaphragm |
