| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE, ISO |
| Model Number: | DMF-Y-40S |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, PayPal |
| Supply Ability: | 10000 pcs per month |
| Port Size: | 1 1/2 Inch | Valve Type: | Submerged |
|---|---|---|---|
| Valve Operation: | Diaphragm Pilot Operated | Coil Voltages: | 24VDC, 110VAC, 220VAC |
| Diaphragm Material: | NBR, FKM | Working Pressure Range: | 1 To 8 Bar |
| High Light: | Pulse Jet Valve Cleaning Dust Filter,MM Series Pulse Jet Valve,Dust Collector Pulse Valve 1 12 Inch |
||
DMF-Y-40S 1 1/2" BFEC Manifold Mount Solenoid Pulse Jet Valve For Bag Filter
The Full Immersion solenoid pulse valve divides the diaphragm into the front and rear air chambers. When the compressed air is connected, the compressed air enters the rear air chamber through the orifice. At this time, the pressure of the rear air chamber will close the diaphragm assembly to the output port of the valve, and the submerged pulse valve is closed.
Technical Data of Dust Collector Pulse Jet Valves:
|
Model Number
|
DMF-Y-25
|
DMF-Y-40S
|
DMF-Y-50S
|
DMF-Y-62S
|
DMF-Y-76S
|
DMF-Y-102S
|
|
Port Size (Inch)
|
1''
|
1 1/2''
|
2''
|
2 1/2''
|
3''
|
4''
|
|
Diaphragm Number
|
1
|
2
|
||||
|
Diaphragm Material
|
NBR, FKM
|
|||||
|
Body Material
|
Aluminum Alloy
|
|||||
|
Pressure Range
|
0.1 to 0.8 MPa
|
|||||
|
Voltage
|
24VDC, 110VAC, 220VAC
|
|||||
Dimension of DMF-Y-40S Pulse Jet Valve:
Video of DMF-Y-40S Pulse Jet Valve:
More BFEC Pulse Valves for you to choose:
|
|
|
|
| Right Angle Type | Quick Mount Type | Straight Through Type | Submerged Type |
|
|
|
|
| Diaphragm | Solenoid Coil | Solenoid Armature | Pulse Controller |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
