TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic

TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic

  • TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic
TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: TN16X20S
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-7 work days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Series: Twin Rod Cylinder Body Material: Aluminum Alloy
Bore Size: 10mm, 16mm, 20mm, 25mm, 32mm Standard Stroke: 10mm To 200mm
Acting Type: Double Acting Operating Pressure Range: 0.1 To 1.0 MPa
Proof Pressure: 1.5 MPa
Highlight:

Airtac Twin-Rod Cylinder

,

Airtac Twin Rod Cylinder

,

Airtac Pneumatic Cylinder TN16X20S

TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic



Shop for dual rod guided air cylinders. Bore sizes range from 10mm to 63mm, and stroke options range from 10mm to 250mm. These double-acting pneumatic cylinders come with a magnet that is available with PT, NPT or G thread types.



To improve load performance, guided pneumatic actuators use guide rods that are installed parallel to the piston rod which provides non-rotating, high side stability. Like rodless cylinders, dual rod air cylinders reduce uneven seal wear, and piston and rod bending.


Specifications of TN Series Twin Rod Pneumatic Cylinder:

TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic 0

Stroke of TN Series Twin Rod Pneumatic Cylinder:

TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic 1


Ordering Code of TN Series Twin Rod Pneumatic Cylinder:
TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic 2

Criteria for selection: Cylinder thrust:

TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic 3



Inner Structure of TN Series Twin Rod Pneumatic Cylinder:

TN16X20S Airtac Type Twin-Rod Guide Air Cylinder Pneumatic 4



Brando Supply Pneumatic Air Cylinders:



Airtac Type Pneumatic Cylinder Festo Type Pneumatic Cylinder SMC Type Pneumatic Cylinder
Airtac Type HFZ Series Air Pneumatic Parallel Gripper Cylinder 6 Airtac Type HFZ Series Air Pneumatic Parallel Gripper Cylinder 7 Airtac Type HFZ Series Air Pneumatic Parallel Gripper Cylinder 8
