| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | CXSM6-10 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-7 work days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Bore Size (mm): | 6, 10, 16, 20, 25, 32 | Standard Stroke (mm): | 10, 15, 20, 25, 30, 35, 40, 45, 50, 60, 70, 75, 80, 90, 100 |
|---|---|---|---|
| Max Operating Pressure: | 0.7 Mpa | Cushion: | Rubber Bumper |
| Port Size: | M5x0.8, 1/8'' | Bearing Type: | Slide Bearing |
| High Light: | Pneumatic Double Rod Cylinder,SMC CXSM6-10 Cylinder,Pneumatic Cylinder Double Rod |
||
Double Rod Guide Air Cylinder Pneumatic CXSM6-10 SMC Type
SMC Type CXS Series Dual Rod Air Pneumatic Cylinder is available in six bore sizes and stroke lengths up to 100mm. This series is very compact and has a very accurate non-rotating specification. It is suited for accurate pick-and-place applications or light duty material handling. The CXS can be used with either reed or solid state switches.
1. Ball bushing bearings and slide bearings are standard for all series.
2. Can be mounted from 3 directions.
3. Workpieces can be mounted on 3 surfaces.
4. Air cushion only minimally adds to full length dimension.
Specifications of CXS Series Pneumatic Cylinder:
Stroke of CXS Series Pneumatic Cylinder:
Ordering Code of CXS Series Pneumatic Cylinder:
Theoretical Output of CXS Series Pneumatic Cylinder:
