DB112/G 1-1/2'' Baghouse Filter Pulse Jet Valve Diaphragm Repair Kit

DB112/G 1-1/2'' Baghouse Filter Pulse Jet Valve Diaphragm Repair Kit

DB112 diaphragm repair kits nitrile membrane mecair 1.5″ pulse valve. Diaphragm repair kit DB112 was suit for MECAIR 1.5″ pulse valve. Diaphragm Material: Proprietary high performance engineering thermoplastic elastomer or Viton. If you need a large quantity, we can give big discount for you.

We produced series Mecair type diaphragm membrane repair kits, it is nice replacement for Mecair diaphragm. The below is DB112/G NBR diaphragm repair kit with stainless steel spring, which is for maintaining the Mecair pusle valves: VNP208, VEM208, VNP308, VEM308, VNP408, VEM408, VNP608, VEM608, VNP708, VEM708. The whole series diaphragm ordering number are DB16, DB18, DB112, DB114, DB116, DB120. If you are looking for others but don't know the diaphragm type of your valve, pls refer to the table below, thanks. If you have other problems or doubts, pls feel free to contact us.

The diaphragm is also called the pulse valve diaphragm. The pulse valve diaphragm is a whole piece of high-quality rubber diaphragm formed by the riveting head of the outlet of the compressed air pipeline or the plug valve, the discharge and unloading hole and the bolt hole with fixed support around it, which is the key control component of the electromagnetic pulse valve. Pulse valve diaphragm is one of the components in the normal operation of the valve body and the "switch" of the jet path of the dust removal system of the pulse bag filter.

The pulse signal is input into the coil in the electromagnetic body through the wire. The pulse valve is controlled by the output signal of the pulse injection control instrument. The pressure change of the two air Chambers before and after the valve makes the rubber diaphragm flex to realize the opening and closing of the pulse valve. The diameter of the rubber diaphragm determines the travel size of the rubber diaphragm and the speed of opening and closing. The larger the diameter of the diaphragm is, the larger the travel will be and the better the spray performance will be.

YouTube video of DB112/G Diaphragm Repair Kit For 1.5'' Mecair Pulse Valve:

Main dimension of NBR Diaphragm For VEM212 VNP212 VEM312 VNP312:

Details display of Membrane For Mecair VEM412 VNP412 Diaphragm Valve:

Available Models of Diaphragm Valve Repair Kits For Mecair Pulse Valves:

Tips: The related solenoid coils and armature assembly are all supplied.

Factory Production Pictures of Solenoid Valve Diaphragm Kits:

Delivery:
1. If the products we have in store, we will send it out ASAP after payment.

2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.

3. Also we can send by your delivery acount if you want.

4. We have a variety of ways to send goods, usually DHL, Fedex, TNL will be normal ways. If you require use of a courier, we can do it.

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
