| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | AE20 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic Bags, Cartons, Pallet |
| Delivery Time: | 4-7 Days |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Product Name: | Diaphragm Repair Kit | Suitable Valves: | AE1818B, AE2818B |
|---|---|---|---|
| Suitable Valve Port Size: | 3/4'' | Diaphragm Material: | TPE |
| Diaphragm Outer Diameter: | φ63.0mm | Seat OD: | φ32.5mm |
| Seat ID: | φ19.5mm | Bleed Hole: | 1 |
| Spring: | Without | Packaging: | Individual Plastic Bag Sealed |
| High Light: | 3/4'' TPE Diaphragm Repair Kit,AE2818B Diaphragm Repair Kit,Autel Type 3/4'' Diaphragm |
||
3/4'' TPE AE1818B AE2818B Pulse Jet Valve Diaphragm Repair Kit
This TPE dipahragm repair kit is use in AUTEL 3/4'' AE1818B and AE2818B pulse valves. Because the diaphragm of pulse valve is a flexible mechanism which needs to open and close frequently to control the air flow, it requires good flexibility and as high sealing as possible. This diaphragm is made of TPE, which has many advantages as following:
1. Good chemical resistance
2. Aging resistance
3. Can be used in a wide temperature range from -40 ℃ to 85 ℃
4. Service life is 4-5 times longer than that of comparable, conven-tional fabric diaphragms.
YouTube video of TPE Diaphragm Repair Kit For AUTEL Pulse Valve:
Main dimension of Diaphragm Repair Kit For 3/4'' AUTEL Pulse Valve:
Details of Diaphragm For AUTEL 3/4'' AE1818B AE2818B Pulse Valve:
Available Models of Diaphragm Valve Repair Kits For AUTEL Pulse Valves:
Factory Production Pictures of Solenoid Valve Diaphragm Kits:
Diaphragm Features:
1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.
2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.
3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.
4. Facbric-reinforced diaphragms advantages:
* No leakage * No Lubrication * No Breakaway Force * No Friction
* Functionality Over Wide Pressure Ranges
* High Strength * Low Cost * Simple Design * Versatility
5. EPDM, Viton all available.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
