| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 2P025-08 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | $3 to $ 5 per pc |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Fluids: | Air, Water, Oil | Action: | Direct Acting |
|---|---|---|---|
| Function: | 2 Way, Normally Closed (NC) | Orifice Size: | 2.5mm |
| Port Size: | 1/4'' | Pressure Range: | 0 To 1.0MPa (0 To 145PSI) |
| Max Pressure Resistance: | 1.5MPa (215PSI) | Body Material: | Plastic |
| Seal Material: | NBR (Standard), VITON (Option) | Min. Action Time: | 0.05 Second And Below |
| High Light: | 2P025-08 Fluid Medium Valves,Plastic Fluid Medium Valves,AirTAC Type 2P025-08 |
||
2P025-08 1/4'' 2 Way Direct Acting Plastic Fluid Medium Valves
Product Features:
1. Safety, applicability, lightweight form factor.
2. For remote electric control fluid conduit in the valve opening and closing.
3. Please note that the gas flow direction and the takeover tooth type is correct installation.
4. With solenoid operated for control appropriate flow and direction, provide great performance.
5. Great body for a long lifespan, perfect for electrically driven pneumatic power control.
Technical Data of 2V Series Pneumatic Solenoid Valves:
Dimension of 2V025-06 Pneumatic Solenoid Valve:
Product Video of 2V025-06 Pneumatic Solenoid Valve:
More Pneumatic Products for you to choose:
2/2 Way 3/2 Way 5/2 Way, Single Solenoid
5/2 Way, Double Solenoid 5/3 Way, Double Solenoid Pneumatic Hose Fittings
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Mia
Tel: +8613454729544
