Water Irrigation Latching Plastic Solenoid Valve 1'' 2'' 3'' 12V 24V

Water Irrigation Latching Plastic Solenoid Valve 1'' 2'' 3'' 12V 24V

  • Water Irrigation Latching Plastic Solenoid Valve 1'' 2'' 3'' 12V 24V
Water Irrigation Latching Plastic Solenoid Valve 1'' 2'' 3'' 12V 24V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 1AA
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Medium: Water Port Size: 1'', 1 1/2'', 2'', 3''
Orifice Size: 25mm, 40mm, 50mm, 80mm Operation: Diaphragm Pilot Operated
Diaphragm Material: NBR Body Material: Plastic (Nylon)
Working Pressure Range: 0.1 To 1.0 MPa Standard Coil Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Latching Coil Voltage: 9-20VDC, Pulse Width (20 To 500mSec) Manual Flow Control: With
High Light:

Latching Solenoid Irrigation Valve

,

Water Solenoid Valve For Irrigation

,

Plastic Irrigation Solenoid Valve

Water Irrigation Latching Plastic Solenoid Valve 1'' 2'' 3'' 12V 24V



A water irrigation solenoid valve is an electrically controlled valve to regulate the flow of water. By applying a voltage over the coil, the valve opens and the liquid can flow through. Solenoid valves are also called electromagnetic valve, water valve, electric valve or electro valve. They have a robust construction and are optionally equipped with manual flow control, so the desired flow can be adjusted. Most models have an override function, the valve can be opened manually if needed. Furthermore, they are equipped with a dirt particle filter. BRANDO irrigation solenoid valves are available with a wide selection of control voltages: 12VDC, 24VDC, 24VAC, 110VAC, 120VAC, 220VAC and 230VAC. The solenoid valves are compatible with almost all automatic irrigation controllers, as long as the control voltage matches.



Technical Data of Irrigation Solenoid Valve:

Model
1AA25
1AA40
1AA50
1AA80
1BA20
1BA25
Orifice Size
25
40
50
80
20
25
Port Size
1''
1 1/2''
2''
3''
3/4''
1''
CV
12
25
45
100
9
12
Working Pressure Range
0.1 to 1.0 MPa
Coil Voltages
Standard Coil: 220VAC, 110VAC, 24VAC (50/60Hz), 24VDC, 12VDC
Latching Coil: DC9-20V, Pulse Width (20 to 500mSec)
Diaphragm Material
NBR
Body Material
Plastic (Nylon)
Manual Flow Control
With
Without



Dimension of Irrigation Solenoid Valve:

Water Irrigation Latching Plastic Solenoid Valve 1'' 2'' 3'' 12V 24V 0

Model
A
B
C
1AA25
140mm
83mm
184mm
1AA40
172mm
89mm
203mm
1AA50
235mm
127mm
254mm
1AA80
230mm
160mm
255mm



Water Irrigation Latching Plastic Solenoid Valve 1'' 2'' 3'' 12V 24V 1

Model
A
B
C
1BA20
112mm
82mm
120mm
1BA25
112mm
87mm
120mm
