1 1/4'' 1 1/2'' 2'' 2 1/2'' Anti Corrosion Solenoid Valve PTFE 24V 220V

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	PTFE

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Product Name:	Anti Corrosion Solenoid Valve	Function:	2 Way, Normally Closed
Port Size:	1 1/4'', 1 1/2'', 2'', 2 1/2''	Orifice Size:	32mm, 40mm, 50mm, 60mm
Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC	Fluids:	Acid & Alkali (Gas, Liquid)
Valve Body Material:	PTFE ()	Seal Material:	FKM, EPDM
Working Pressure Range:	0.01 To 0.6 MPa
High Light:	24V Anti Corrosion Solenoid Valve , 2 Inch Anti Corrosive Solenoid Valve , 220V Anti Corrosive Solenoid Valve

1 1/4'' 1 1/2'' 2'' 2 1/2'' Anti Corrosion Solenoid Valve PTFE 24V 220V

BRANDO manufactures PTFE solenoid valve with excellent anti-corrosive performance. As we know, stainless steel materials may be corroded by corrosive media, so we are sincerely recommend this PTFE solenoid valve for you. Well for corrosive medium fluid control such as nitricalid, hydrochloricacid, etc. Widely used in chemical industry, medical industry, etc.

1. Port Size Range: 1/8", 1/4", 3/8", 1/2", 3/4", 1'', 1 1/4'', 1 1/2'', 2'', 2 1/2''
2. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
3. Voltage Tolerance: +10%
4. Temperature range: -10°C to 80°C (14°F to 176°F)
5. Function: Normally Closed
6. Valve Material: PTFE
7. Pressure: 0.01 to 0.6 MPa
8. Connection Type: Threaded, Flanged
9. Suitable Medium: Corrosive Fluid, Acid, Alkali, etc
10. Applications: Chemical, Medical indistry and other applications which require anti-corrosion.
11. We also provide PTFE ball valve and PTFE butterfly valve for you.
12. Any special requirements, please consult us and we will help you resolve the issue and select the right solenoid valve basic on your requirements.

Technical Data of Body Solenoid Valve:

Model		PTFE-15	PTFE-20	PTFE-25	PTFE-32	PTFE-40	PTFE-50	PTFE-65
Port Size		1/2''	3/4''	1''	1 1/4''	1 1/2''	2''	2 1/2''
Orifice Size		15mm	20mm	25mm	32mm	40mm	50mm	60mm
Cv Value		4	5.5	13	17	25	40	62
Medium		Weak Acid & Alkali (Gas, Liquid)
Working Pressure		0.01 to 0.6MPa
Working Temperature		Max. +180℃
Seal Material		FKM, EPDM
Voltage	220VAC	15W			Start: 200W Keep: 5W		Start: 350W Keep: 10W
	24VDC	16W			28W		Start: 75W Keep: 25W

Main Dimension of PTFE Body Solenoid Valve:

1'' Anti Corrosive Solenoid Valve PTFE Body 24V DC 220V AC 0

Model	Dimension
Model	D	H	E	A	M	L	K	F
PTFE-15	70	127	56.5	18.5	M5	14	92	58
PTFE-20	80	136	70.5	20	M6	10	92	67
PTFE-25	95	145	78	25	M6	12	92	75
PTFE-32	120	200	110	31	M8	20	94	98
PTFE-40	130	220	113	33.5	M8	18	94	106
PTFE-50	150	249	140	43	M10	20	94	116
PTFE-65	180	262	152	49	M10	25	94	116
