MP-C-080 MP-C-082 238210-032-D 14mm Hole Red Hat Solenoid Coil

MP-C-080 MP-C-082 238210-032-D 14mm Hole Red Hat Solenoid Coil

The MP-C-080 ASCO Type Solenoid Coil is a flying lead-type thermosetting coil, the size is φ14mm x 39mm x 50mm, the standard voltage is AC220V, AC110V, DC24V. The power is 18Watt, 21 volts. It can replace the ASCO electromagnetic coil and is used for dust collector pulse valves, two-position two-way solenoid valves, two-position three-way solenoid valves, two-position four-way solenoid valves and other solenoid valves, such as 8262H001, 8262H014, 8262H002, 8262H002V, 8262H006, 8353G041, 8353G041, 8353G053, Solenoid valves such as EF8262H014, EF8262H002, EF8262H022, EF8262H007, K3A662U, 8300D009U, S262SG02N3GJ7, S262SG02N3EG5.

Solenoid Valve Coil Voltages
Solenoid valve coils are available for both DC and AC electricity. Although a coil can be made to work with almost any imaginable voltage, the most common voltages available are:

6-Volt DC
12-Volt DC
24-Volt DC
24-Volt AC
120-Volt AC
220/240-Volt AC

The advantage of the low voltage coils is obviously electrical safety. Hobbyists and do-it-yourselfers often power the low voltage solenoid valves with wall transformers. Most smaller valves 12 VDC valves can be powered by a 12-Volt / 500 mA power supply. However, always make sure your power supply does meet or exceed the power requirement of the solenoid. The 24 VAC solenoid valves appeal to hobbyists as well since they can be easily controlled by irrigation timers. Most industrial applications and heavy machinery use solenoids with 24 VDC coils.

Dimension of BB14339732 Solenoid Valve Coil :

Technical Data:

Solenoid Coil Production Line:

Attention:​
1. This air suspension compressor pump solenoid coil is made of high quality components.

2. Replaces the original air compressor solenoid coil of your car and equal the original quality.
3. Please double confirm the compatibility as well as the OEM number before purchasing.
4. Instruction is not included. Professional installation is recommended.

Steps and methods for properly installing a solenoid valve coil:

1. Check if the solenoid valve and the selected parameters are the same, such as differential pressure, etc. If the error occurs, the solenoid valve coil will be burned out. Voltage fluctuations should be within the normal range and meet the rated voltage.

2. Before connecting the pipeline, flush the pipeline and remove the residual dirt in the pipeline. If there are residual stains, it will affect the normal use of the solenoid valve. To prevent this, a filter should be installed in the pipeline.

3. Install the solenoid valve coil of the solenoid valve vertically on the horizontal and ground pipes. If there is a special situation, it cannot be installed vertically. The appropriate solenoid valve should be ordered in advance, otherwise the solenoid valve will not work properly.

4. When installing, add a safety process and install a manual cutting valve to facilitate maintenance in case of failure.

5. Pay attention to the direction when installing, can not be reversed, installed in the direction indicated on the package, and can be reversed in some special cases such as vacuum.

6. If the water may be damaged by the medium, you must take appropriate protective measures or choose a solenoid valve with a waterproof hammer function.

7. The solenoid valve cannot be energized all the time, otherwise it will reduce its life. Note that normally open, normally closed solenoid valves cannot be used with care.

Product Features:
1. Using high quality wire which has UL approved; 2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
