BD-C 8mm Hole 6011 6012 Plunger Electrical Solenoid Coil 230vac

BD-C 8mm Hole 6011 6012 Plunger Electrical Solenoid Coil 230vac

  • BD-C 8mm Hole 6011 6012 Plunger Electrical Solenoid Coil 230vac
  • BD-C 8mm Hole 6011 6012 Plunger Electrical Solenoid Coil 230vac
BD-C 8mm Hole 6011 6012 Plunger Electrical Solenoid Coil 230vac
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BB08029101
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Hole Size: 8.0mm Height: 29.0mm
Width: 19.6mm Voltage: 24V DC, 24V AC, 110V AC, 230V
Power: 5VA Connector: DIN43650B
Insulation Class: F, H Protection Class: IP65, IP67, IP68
Application: 6011, 6012 Solenoid Valve
High Light:

8mm Hole solenoid coil 230vac

,

6011 6012 solenoid coil 230vac

,

BD-C Solenoid Valve Coil

 BD-C 8mm Hole 6011 6012 Plunger Solenoid Valve Electrical Coil



Applicable Industries:Solenoid Valve
Type:Fittings
Place of Origin:Zhejiang, China
Brand Name:Brando
Hole Size:8mm
Height:29mm
Width:19.6mm
Voltage:24V DC, 24V AC, 110V AC, 230V
Power:5VA
Connection Type:DIN43650B
Insulation class:F, H
Protection class:IP65, IP67, IP68
Application:6011, 6012 Solenoid Valve



Dimension of 6012/6011 Type Solenoid Valve Coil :



Dimension of 6012/6011 Type Solenoid Valve Coil :

Technical Data:

Model
BB08029101
Hole size
8mm
Height
29mm
Width
19.6mm
Voltages
DC24V, Ac24V, AC110V, AC220V
Power
5VA
Insulation class
F, H
Connection Type
DIN43650B
Application examples
6011, 6012 Solenoid Valve





Details:

D2 d3 d4
Hole size 8.0mm Height 29.0mm Width 19.6mm



Solenoid Coil Production Line:



BD-C 8mm Hole 6011 6012 Plunger Electrical Solenoid Coil 230vac 4



Attention:
1. This air suspension compressor pump solenoid coil is made of high quality components.

2. Replaces the original air compressor solenoid coil of your car and equal the original quality.
3. Please double confirm the compatibility as well as the OEM number before purchasing.
4. Instruction is not included. Professional installation is recommended.





Why does a coil get burnt when removed from valve?

This is because with AC 50/60Hz coils you are reducing the impedance or resistance of the coil, as the shading ring within the armature or stem generates resistance within the coil. By removing the coil whilst powered the resistance is reduced thus the power consumption can easily increase above the coil winding class limits causing over heating.



Steps and methods for properly installing a solenoid valve coil:

1. Check if the solenoid valve and the selected parameters are the same, such as differential pressure, etc. If the error occurs, the solenoid valve coil will be burned out. Voltage fluctuations should be within the normal range and meet the rated voltage.

2. Before connecting the pipeline, flush the pipeline and remove the residual dirt in the pipeline. If there are residual stains, it will affect the normal use of the solenoid valve. To prevent this, a filter should be installed in the pipeline.

3. Install the solenoid valve coil of the solenoid valve vertically on the horizontal and ground pipes. If there is a special situation, it cannot be installed vertically. The appropriate solenoid valve should be ordered in advance, otherwise the solenoid valve will not work properly.

4. When installing, add a safety process and install a manual cutting valve to facilitate maintenance in case of failure.

5. Pay attention to the direction when installing, can not be reversed, installed in the direction indicated on the package, and can be reversed in some special cases such as vacuum.

6. If the water may be damaged by the medium, you must take appropriate protective measures or choose a solenoid valve with a waterproof hammer function.

7. The solenoid valve cannot be energized all the time, otherwise it will reduce its life. Note that normally open, normally closed solenoid valves cannot be used with care.
