| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | MP-08 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | $3 to $ 5 per pc |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Working Medium: | Air (to Be Filtered By 40 μm Filter Element) | Valve Type: | 4 Way 2 Position |
|---|---|---|---|
| Port Size: | 1/4'' | Working Pressure Range: | 0.08 To 0.35 MPa |
| Body Material: | Aluminum Alloy | Seal Material: | Silicone |
| Wiring Form: | Lead Wire Or DIN43650 Connector | Voltages: | 12VDC, 24VDC |
| High Light: | Solenoid Valve For Oxygen Generator,Solenoid Valve For Oxygen Machine,4 Way 2 Position Oxygen Generator Solenoid Valve |
||
1/4'' 4 Way Solenoid Valve For Medical Oxygen Generator 12V 24V
Applications: This solenoid valve is popularly used in the low pressure system, especially use for O2 Oxygen generator system of medical Industrial.
Product Features:
1. Low presure solenoid valve;
2. Aluminum alloy material valve body;
3. 2 position 4 way, Diaphragm pilot operated;
4. Working at low pressure from 0.08MPa to 0.35MPa, Sensitive to low pressure;
5. Vertical mounting direction and horizontal direction for option;
6. DIN43650 electricity connection and flying wire type for selectable;
7. Special fomular silicone ensure long serivce life.
Technial Data of Oxygen Solenoid Valves:
| Model | MP-08 |
| Valve Type | 4 Way 2 Position |
| Working Medium | Air (to be filtered by 40 μm filter element) |
| Action | Internal Pilot Operated |
| Body Material | Aluminum Alloy |
| Seal Material | Silicone |
| Working Pressure Range | 0.08 to 0.35 MPa |
| Working Temperature Range | -5 to +80℃ |
| Coil Insulation Class | F Class, IP65 |
| Coil Voltage | 12VDC, 24VDC |
| Coil Power | 3W, 1.5W |
Dimension of Oxygen Solenoid Valve:
 |
|
|
|
Production Video of Pneumatic Solenoid Valve:
