| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | MP-08 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 pcs per month |
| Working Medium: | Air (to Be Filtered By 40 μm Filter Element) | Valve Type: | 4 Way 2 Position |
|---|---|---|---|
| Port Size: | 1/4'' | Working Pressure Range: | 0.08 To 0.35 MPa |
| Body Material: | Aluminum Alloy | Seal Material: | Silicone |
| Wiring Form: | Lead Wire Or DIN43650 Connector | Voltages: | 12VDC, 24VDC |
| Highlight: | Oxygen Generator Solenoid Valve,Solenoid Valve For Oxygen,Solenoid Valve For Oxygen Service |
||
1/4'' 4 Way 2 Position Oxygen Generator Solenoid Valve 12VDC 24VDC
Applications:
This solenoid valve used in the low pressure system, especially use for O2 Oxygen generator system of medical Industrial.
Product Features:
1. Low presure solenoid valve.
2. Aluminum alloy material valve body.
3. 2 position 4 way, Diaphragm pilot operated.
4. Working at low pressure from 0.08MPa to 0.35MPa, Sensitive to low pressure.
5. Vertical mounting direction and horizontal direction for option.
6. DIN43650 electricity connection and flying wire type for selectable.
7. Special fomular silicone ensure long serivce life.
Technial Data of Oxygen Solenoid Valves:
| Model | MP-08 |
| Valve Type | 4 Way 2 Position |
| Working Medium | Air (to be filtered by 40 μm filter element) |
| Action | Internal Pilot Operated |
| Body Material | Aluminum Alloy |
| Seal Material | Silicone |
| Working Pressure Range | 0.08 to 0.35 MPa |
| Working Temperature Range | -5 to +80℃ |
| Coil Insulation Class | F Class, IP65 |
| Coil Voltage | 12VDC, 24VDC |
| Coil Power | 3W, 1.5W |
Dimension of Oxygen Solenoid Valve:
 |
|
|
|
Production Video of Pneumatic Solenoid Valve:
