| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | MP-08 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 pcs per month |
| Working Medium: | Air (to Be Filtered By 40 μm Filter Element) | Valve Type: | 4 Way 2 Position |
|---|---|---|---|
| Port Size: | 1/4'' | Working Pressure Range: | 0.08 To 0.35 MPa |
| Body Material: | Aluminum Alloy | Seal Material: | Silicone |
| Wiring Form: | Lead Wire Or DIN43650 Connector | Voltages: | 12VDC, 24VDC |
| Highlight: | Solenoid Valve For Oxygen,Solenoid Valve For Medical,Solenoid Valve For Oxygen Generator |
||
1/4'' 4/2 Way 12V 24V Solenoid Valve For Medical O2 Oxygen Generator
Product Features:
1. Adopt new processing, improved inner hole roughness.
2. Adopt specially formulated silicone to increase of service life.
3. To import German high standard special grease which provides film in order to reduce the friction.
4. Valve spool material use soft magnetic stainless steel from German,increase the magnetic properties and reduce the coil power to 30%.
5. Low pressure system valve for medical application.
6. Special fomular silicone for longer service life.
Technial Data of Oxygen Solenoid Valves:
| Model | MP-08 |
| Valve Type | 4 Way 2 Position |
| Working Medium | Air (to be filtered by 40 μm filter element) |
| Action | Internal Pilot Operated |
| Body Material | Aluminum Alloy |
| Seal Material | Silicone |
| Working Pressure Range | 0.08 to 0.35 MPa |
| Working Temperature Range | -5 to +80℃ |
| Coil Insulation Class | F Class, IP65 |
| Coil Voltage | 12VDC, 24VDC |
| Coil Power | 3W, 1.5W |
Dimension of Oxygen Solenoid Valve:
 |
|
|
|
