| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | FV-02 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Fluid: | Air (to Be Filtered By 40μm Filter Element) | Operation: | Acting Type Controlled By Foot Normally Closed |
|---|---|---|---|
| Port Size: | 1/4'' | Valve Type: | 3 Way 2 Position |
| Pressure Range: | 0 To 1.0 MPa | Max Pressure Resistance: | 1.5 MPa |
| Temperature Range: | -20 To +70℃ | Body Material: | Aluminum Alloy |
| High Light: | Pneumatic Foot Operated Pedal Valve,Foot Pedal Air Valve,FV-02 |
||
FV-02 1/4'' 3 Way 2 Position Pneumatic Foot Operated Pedal Valve
Pneumatic foot valves or foot pedal valves are used to operate devices, such as cylinders, or to hold work pieces in place enabling hands free machine operation. Foot pedals are available as latching or spring return - latching versions can be used to lock work pieces in place whilst spring return versions are used to perform repetitive functions like dosing, pressing, punching or drilling.
Technical Data of FV series Foot Pedal Valve:
| Model | FV-02 | FV-320 | FV-420 |
| Fluid | Air (to be filtered by 40μm filter element) | ||
| Operating | Acting type controlled by foot | ||
| Port Size |
1/4'' |
In=Out=1/4'', Exhaust=1/8'' |
In=Out=1/4'', Exhaust=1/8'' |
| Valve Type | 3/2 Way | 3/2 Way | 4/2 Way |
| Pressure Range | 0 to 1.0 MPa (0 to 145 psi) | ||
| Proof Pressure | 1.5 MPa (215 psi) | ||
| Temperature | -20 to +70℃ | ||
| Body Material | Aluminum Alloy | ||
Dimension of FV-02 Foot Pedal Valve:
