| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 3FM210-06 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Fluid: | Air (to Be Filtered By 40μm Filter Element) | Operation: | Acting Type Controlled By Foot Normally Closed |
|---|---|---|---|
| Port Size: | 1/8'' | Valve Type: | 3 Way 2 Position |
| Pressure Range: | 0 To 1.0 MPa | Max Pressure Resistance: | 1.5 MPa |
| Temperature Range: | -20 To +70℃ | Body Material: | Aluminum Alloy |
| High Light: | Foot Pedal Pneumatic Valve,Foot Pedal Valve Airtac,Airtac 3FM210-06 |
||
3FM210-06 Airtac Type Mini Foot Pedal Pneumatic Control Valve
Application
These valves are used as directional control valves to operate pneumatic cylinders (single or double acting).
Function
1. A 5/2 foot operated valve connected to a pneumatic cylinder (double acting type), when pressed once and released, makes the cylinder piston to move in the forward direction and continuously keeps in that direction. When it is again pressed the lock is released and the pedal returns back due to a spring, and thus the cylinder retracts back to its home position.
2. Similarly a 3/2 foot operated valve, can be used to operate a single acting cylinder.
Technical Data of 3F, 3FM series Foot Pedal Valve:
| Model | 3F210-M5 | 3F210-06 | 3FM210-06 | 3F210-08 | 3FM210-08 |
| Fluid | Air (to be filtered by 40μm filter element) | ||||
| Operating | Acting type controlled by foot normally closed | ||||
| Port Size |
M5 |
1/8'' |
1/8'' |
1/4'' |
1/4'' |
| Valve Type | 3/2 way | ||||
| Pressure Range | 0 to 1.0 MPa (0 to 145 psi) | ||||
| Proof Pressure | 1.5 MPa (215 psi) | ||||
| Temperature | -20 to +70℃ | ||||
| Body Material | 3FM: Plastic, 3F: Aluminum Alloy | ||||
Ordering Code of 3F, 3FM series Foot Pedal Valve:
Inner Structure of 3F, 3FM series Foot Pedal Valve:
Dimension of 3F, 3FM series Foot Pedal Valve:
Production Video of BRANDO Pneumatic Valves:
