CA89MM 3-1/2'' Inch Manifold Flat Mount Dust Collector Pulse Jet Valve

CA89MM 3-1/2'' Inch Manifold Flat Mount Dust Collector Pulse Jet Valve

The full immersion manifold flat mount valves of the Goyen MM deliver the most powerful air pulse in square tank systems. When included in a fluid control and/or regulation system, valve manifolds have shown to improve efficiency as well as reduce energy costs. These diaphragm valves are designed for dust collectors and baghouses with reverse pulse jet filter cleaning systems.

Youtube Video About CA89MM Double Diaphragm Solenoid Pulse Valve:

Technical of CA89MM 3 Inch Dust Collector Electromagnetic Valve:

Main Dimension of Reverse Pulse Jet Valve:

Details About CA89MM Diaphragm Valve AC220V AC110V AC24V DC24V:

The factors that affect the length of the bag filter bag of an industrial dust collector are:
1. The number of filter bags is reduced, and the equipment area is small: Under the condition of the same processing air volume, filter wind speed and bag diameter, the increase in the length of the dust bag will increase the filter area of ​​a single bag, thereby reducing the number of filter bags and reducing the area area;
2. The number of bags is reduced, so the solenoid valve, pulse valve, blowing pipe and other parts of the dust removal system will also be reduced, saving investment and shortening the dust removal cycle of the dust collector.
3. Excessive length of the filter bag will increase the manufacturing cost: the height of the industrial dust collector box will increase, and the upward extension will increase the strength of the component, so the equipment manufacturing cost will increase.
4. Poor dust removal effect: when the industrial dust collector bag is used for online dust removal, the longer the filter bag, the greater the possibility that the dust sprayed out of the bag will be re-absorbed and will be absorbed into the bag; if the dust is removed offline, the longer the bag will be The suspension time should also be prolonged, and the slower the recovery and filtration of the cleaning chamber;
5. The bag is easy to damage: the longer the dust bag, in order to ensure an effective dust removal effect, the stronger the blowing energy needs to be maintained, the greater the blowing potential energy, the more likely the dust bag is to be damaged;
6. If the filter bag is too long, installation, maintenance and inspection will be inconvenient.

Construction:
Body and Dreeser Nuts: Aluminum (diecast)
Ferrule: 305 Stainless Steel
Armature: 430FR Stainless Steel
Diaphragm and Seals: Nitrile or FKM
Spring: 304 Stainless Steel
Screws: 302 or 304 Stainless steel
Outlet Pipe: Schedule 40 wrought steel zinc passivated
Diaphragm Seat: PA-66 (25 & 40MM standard), Nitrile-coated mild steel (76MM standard), Acetal (102MM standard) or FKM coated mild steel
