| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | TSV8652 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Product Name: | Hand Control Valve | Fluid: | Compressed Air |
|---|---|---|---|
| Port Size: | 1/8'', 1/4'', 3/8'', 1/2'' | Valve Type: | 5 Way 2 Position |
| Pressure Range: | 0 To 9 Kgf/cm² | Max Pressure Resistance: | 10 Kgf/cm² |
| Temperature Range: | -10 To +60℃ | Body Material: | Aluminum Alloy |
| High Light: | Shako Hand Control Valve,Air Hand Control Valve,Shako TSV8652 |
||
TSV8652 Series Shako Type 5/2 Way Hand Control Air Valves
The Shako type TSV8652 hand control valve series, which is a functional replacement for the Airtac 4H series and SMC VZM400 series.
Product Features:
1. HIGH-QUALITY MATERIAL: High-quality brand new tire change arm control air valve. Made of high-quality aluminum alloy material, it has high durability. Long service life, and not easy to damage, can save the number of replacements, and save costs
2. AUTOMATIC RESET: The middle position can be the spring center position. It controls the on or off of the air flow, and the On / Off switch can reset itself. The quality is reliable, and other accessories will not be damaged due to damage to replacement parts.
3. STRONG STABILITY: The product has undergone rigorous testing, advanced performance and durability. High qualitative, excellent performance and reliable operation.
Technical Data of TSV8652 series Hand Control Valve:
| Model | TSV8652(R)-01M(S) | TSV8652(R)-02M(S) | TSV8652(R)-03M(S) | TSV8652(R)-04M(S) |
| Port Size |
In=Out= Exhaust=1/8'' |
In=Out=1/4'', Exhaust=1/8'' |
In=Out= Exhaust=3/8'' |
In=Out= Exhaust=1/2'' |
| Body Material | Aluminum Alloy | |||
| Fluid | Compressed Air | |||
| Sectional Area | 14mm² | 18mm² | 35mm² | 38mm² |
| Operating Pressure Range | 0 to 9 kgf/cm² | |||
| Proof Pressure | 10 kgf/cm² | |||
| Ambient Temperature | -10 to +60℃ | |||
Ordering Code of TSV8652 series Hand Control Valve:
Dimension of TSV8652-02 Hand Control Valve:
Explosion of TSV8652 series Hand Control Valve:
Production Video of BRANDO Pneumatic Valves:
More Pneumatic Products for you to choose:
| 2/2 Way Pneumatic Valves | 3/2 Way Pneumatic Valves | 5/2 Way Pneumatic Valves | 5/3 Way Pneumatic Valves |
|
|
|
|
| Namur Solenoid Valves | FRL Unit | Pneumatic Cylinders | Silencers and Fittings |
|
|
|
|
