| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | TSV8652-02S |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 pcs per month |
| Product Name: | Hand Control Valve | Fluid: | Compressed Air |
|---|---|---|---|
| Port Size: | In=Out=1/4'', Exhaust=1/8'' | Valve Type: | 5 Way 2 Position |
| Pressure Range: | 0 To 9 Kgf/cm² | Max Pressure Resistance: | 10 Kgf/cm² |
| Temperature Range: | -10 To +60℃ | Body Material: | Aluminum Alloy |
| Highlight: | Hand Control Air Valve,Shako Hand Control Valve,Shako TSV8652-02S |
||
TSV8652-02S Shako Type Hand Control Air Valve 5 Way 2 Position
Product Features:
1. The Valve Body is Made of High Precision Aluminum with High Hardness and Long Service Life.
2. Air Inlet Port with 0.04mm Filter Screen, Can Filter Most Impurities and Dust, Keep the Valve Body Clean, Prolong Service Life.
3. Each Thread is Finely Processed, No Burrs, Smooth and Easy to Install.
4. The Valve Body Contains a High Concentricity Seal Ring, Which is Not Easy to Leak, and the Rubber Pad with Lubricating Oil Reduces Friction.
5. Each Product Comes with Fittings That Can Be Used Directly. No Need to Buy Additional Accessories, Just Insert 6mm or 1/4'' tube.
6. The Inner Hole is Processed by Special Process, with Small Friction Resistance and Long Service Life.
7. Driven Automatically by Compressed Air. with Hand Lever, Can Be Controlled Manually to Deal with Some Special Situations.
8. Widely Used to Control the Flow of Various Types of Fluids Such As Air, Water, Mud, Liquid Metals, Etc.
9. The 5 port 2 position Manual Reset Type Manual Valve Adopts Spring Steel Ball Positioning, Which is Responsive and Easy to Switch. Please Pay Attention to Excessive Force and Control Position Error Caused by Mistake.
Technical Data of TSV8652 series Hand Control Valve:
| Model | TSV8652(R)-01M(S) | TSV8652(R)-02M(S) | TSV8652(R)-03M(S) | TSV8652(R)-04M(S) |
| Port Size |
In=Out= Exhaust=1/8'' |
In=Out=1/4'', Exhaust=1/8'' |
In=Out= Exhaust=3/8'' |
In=Out= Exhaust=1/2'' |
| Body Material | Aluminum Alloy | |||
| Fluid | Compressed Air | |||
| Sectional Area | 14mm² | 18mm² | 35mm² | 38mm² |
| Operating Pressure Range | 0 to 9 kgf/cm² | |||
| Proof Pressure | 10 kgf/cm² | |||
| Ambient Temperature | -10 to +60℃ | |||
Ordering Code of TSV8652 series Hand Control Valve:
Dimension of TSV8652-02 Hand Control Valve:
Explosion of TSV8652 series Hand Control Valve:
Production Video of BRANDO Pneumatic Valves:
